1" Air Diaphragm Pump

Brand:Nuodean

Description:NUODEAN'S WA Series air operated diaphragm pumps have almost the same appearance and performance as the Pro series of ARO brand, and are interchangeable with ARO brand,but with cheaper price. They are ideal for general industrial and OEM installation applications.

Origin:China

Model:WA6661X

Product detail:Air Inlet(female): 1/4"BSPT(1/4"NPT Available On Request)
Fluid Outlet(female): 1"BSPT Or 1"NPT
Fluid Inlet(female): 1"BSPT Or 1"NPT
Maximum Flow Rate: 35GPM(133LPM)
Max. Operating Pressure: 120psi(8.3bar)
Suspended Solids Max. Dia.:  1/4"(6.4mm)
Maximum Dry Suction Lift:  20feet(6.1m)
Weight:
WA666100-X-C(aluminum)19 lbs(8.6kg)
WA666101-X-C(stainless steel)36 lbs(16.3kg)
WA666102-X-C(Cast Ironl)31 lbs(14.1kg)
Displacement Per Cycle: 0.16Gallons(0.60Liters)
Sound Level:70psi     50 cycles/min.    81.0db(A)
