Brand:HT Italia
Description:SPEED418 is an innovative Loop/RCD tester designed to perform Global Earth Resistance test without RCDs' tripping directly on sockets. It is also suitable for all RCDs' tests on trip out time and current both manually and automatically on electrical installations in compliance with standards (VDE0100, BS7671 etc..). Another important test is Loop impedance measurement with high resolution (0.1mOhm) (with optional accessory IMP57). The Loop/RCD tester SPEED418 is very user-friendly, extremely rugged thanks to its newest electronic range selector. Moreover the instrument permits to carry out main measurements by using a special remote switch probe (optional accessory PR400) particularly useful to perform several tests in rapid succession. A contextual on-line help menu selectable by user is available for each function so granting information during connection between tester and installations. A wide internal memory permits saving any measurement and later transferring them to PC via serial port and software. Each measurement can be saved with all sub-results and test parameters as well as with two ID locators (selectable by user) in order to better trace the exact point where measurement was performed.
Origin:Other country Italy
Model:SPEED 418
Payment Terms:T/T
Packaging Details:CARTON BOXES
Product detail:
- Global Earth Resistance without RCD tripping
- Trip out time of RCDs type AC, A Standard and Selective
- Trip out current of RCDs type AC, A Standard and Selective up to 1A
- Loop Impedance P-P, P-N, P-PE
- Loop Impedance with high resolution (with IMP57 optional accessory)
- Prospective short circuit current
- Contact voltage
- Phase sequence indication
- Measure with remote probe (with PR400 optional accessory)
- Contextual help at display
- Internal memory
- Optical-USB interface with PC connection
Codmetel : HV000418
- C2033X : Cable 3 wires with Shuko plug
- BORSA75N : Soft carrying bag
- ISO9000 calibration certificate
- User manual on CD-ROM
- Quick reference guide
- TOPVIEW2006 : Windows software + optical/USB cable C2006
- UNIVERSALKIT : Set 3 cables + 3 alligator clips + 1 test lead
- IMP57 : Accessory for high resolution Loop/Line Impedance
- PR400 : Remote lead per activation test
- SP-0400 : Set of straps for use of meter on neck
CE MARK
EN 61008
IEC/EN61187
IEC/EN61557-1
IEC/EN61557-2
IEC/EN61557-3
IEC/EN61557-4
IEC/EN61557-6
IEC/EN61557-7
LVD 2006/95/CE Directive
VDE 0100
