Installation tester

Brand:HT Italia

Description:The multifunction installation tester EQUITEST5071 model is principally designed to perform the safety verifies of earth equipotential conductors with test current > 10A in compliance with IEC/EN61557, VDE100 and IEC/EN60204-1:2006 guidelines (medical rooms and safety of electrical machines). The instrument performs even continuity measurements with 200mA, Line/Loop impedance also with high resolution (0.1mOhm – with IMP57 optional accessory), global earth resistance without RCDs tripping and phase sequence indication. Each test can be saved inside the internal memory and downloaded to PC by using supplied Windows software.

Origin:Other country Italy

Model:EQUITEST5071

Payment Terms:T/T

Packaging Details:carton boxes

Product detail:

Function

• Continuity on protective conductors with 200mA
• Continuity on protective conductors with 10A and voltage <12V
• Continuity with 10A in compliance with IEC/EN60204-1:2006
• 4 wires measurement method
• Line/Loop impedance with calculation of the prospective short circuit current
• Line/Loop impedance with high resolution (with IMP57 optional accessory)
• Global earth resistance without RCDs tripping
• Contact voltage
• Phase rotation with 3 wires method
• Save results inside memory
• Recall measured test at display
• Optical/USB interface for PC communication
• Auto Power OFF
• Backlight

Codmetel : HV005071
