Car DVD For Android Geely EC7 with GPS
| A9 Platform Android Car DVD hardware Configuration |
| The core CPU: Renesas Cortex-A9 double core 1.5G |
| CPU:Dual-Core ARMv7 Processor |
| Operation System:Android 4.0 |
| System Memory RAM:512M SAMSUNG |
| Built-in Memory: ROM: 4G/system(1.5G)/Partition memory(2.5G) SanDisk |
| External TF Card:support Max 32G |
| GPU:Power VR SGX530/OPEN GL-CM1.1 |
| 1080P Video Format:RMVB,AVI,MOV,MKV,3GP,MP4 etc. |
| Screen Material:TFT Hanstar |
| TFT drive:TW8816 |
| Screen resolution:800*480 |
| back light LED:MP3302/YB1517+APW7077 |
| Master control MCU: STM32F100 |
| Audio processing:BD3702 |
| Voice Sound:ALC5621 |
| Video conversion:FMS6502 |
| Power amplifier:ST/TDA7388 4*25W BTL |
| USB extension:GL850 USB2.0*4 |
| Radio:NXP/TEF6621 |
| GPS Model:UBLOS 650A |
| BT:CSR/BC57K68 |
| Power DC:IIC/AP1530 |
| DVD decode:SUNPLUS 8202VGQ |
| DVD RAM:WINBOND 128M |
| DVD Video Support: 720P |
| Servo drive:AM5888 |
| FLASH SPI:Cfeon 25T16 2M |
| DVD Memory:ATM24C02 |
| DVD Chip:HuaYang DL-30 double disk |
| working power voltage:DC/6V-16V.Conventional voltage 14.4V |
| Optional Functions:USB,WIFI,3G Phone,Car Recorder,CAN agreement. |
Android A9 Platform Car DVD Functions
Used Renesas Arm Cortex-A9 Dual Core Processor, the core frequency 1.2GHz.
Support 2D/3D Graphics Accelerator, more fast and convenient for 3D Navigation.
Support 1920*1080P resolution and RMVB,RM, AVI, MP5 Video format play.
Built in DDR2 512MB/4GB Memory.
Android 4.0 platform (2.3 optional).
Touch screen Input Operation (Five point touch capacity screen, resistive screen casual replacement).
Built in DVD Play, suction chip for special Car DVD.
Built in Radio, AM/FM, storage of 30 stations.
Built in Stereo Bluetooth hands-free phone functions.
Special audio and video decoding software, play USB/SD automatically.
Built in GPS Receiver.
iPod connect control function ( cable is optional).
High resolution of TFT Digital Display (800*480).
Built in 45WX4 power amplifier, High-fidelity 4.1 -channel line output.
Reverse line detection, a second display appear.
External 3G network, Wifi module (can be connected through front USB port and back USB extension line).
Dynamic desktop can be download and replacement, many Android Games can be installed.
Car recorder function, Large display show, more convenient for operation (optional).
360 - degree panoramic display. (Optional)
Voice recognition function, can realize mobile phone voice input and search function (optional).
