SAIPA141 DLX
| Basic | |
| Overall length | 3935 mm |
| Overall width | 1605 mm |
| Overall height | 1455 mm |
| Wheel base | 2345 mm |
| Tread, front | 1405 mm |
| rear | 1385 mm |
| Seating capacity | 5 |
| Ground clearance | 160 mm |
| Fuel tank capacity | 37 lit |
| Min. turning radius | 4.55 m |
| Engine | |
| Model | M13NI |
| Type | 4-Cylinder, in line, SOHC |
| Bore & storke | 71.0 * 83.6 mm |
| Displacement | 1323 cc |
| Compression ratio | 9.7 : 1 |
| Fuel supply system | Injection |
| Max .power | 62.5/5200 hp/rpm |
| Max. torgue | 103.3/2500 Nm/rpm |
| Engine oil capacity | 3.4 Lit |
| Drive Trine | ||
| Clutch Single dry plate, diaphragm springs | ||
| Transmission | 5- Speed manual | |
| Gear Ratio
| 1st | 3.454 |
| 2nd | 1.944 | |
| 3rd | 1.275 | |
| 4th | 0.861 | |
| 5th | 0.692 | |
| rev | 3.583 | |
| Final gear ratio | 3.778 | |
| Chassis | |
| Frame | Monocoque |
| Suspension, front | independent by MacPherson struts ,coil spring |
| Rear | torsion beam type ,coil springs |
| shock absorbers ,front/rear | double acting shock absorbers |
| steering ,mechanical | rack & pinion |
| steering , hydraulic (optional) | rack & pinion, hydraulic |
| Brakes System | dual circuit hydraulic with vacuum assistant |
| Front | discs |
| Rear | leading and trailing drums |
| Options & Accessories |
| Air conditional system |
| central locking system |
| front power windows |
| tinted glass |
| power antenna |
| tachometer |
| fuel evaporating control system |
| tilt steering |
| rear window heater |
| Fuel filler lid release |
| lift gate electric release |
| digital AM/FM radio/CD player with 4 speaker |
| front & rear seat safety belts |
| adjustable side mirrors with inner knob |
| 2 speed wipers with variable intermittent speed |
| Auto choke |
| reclining front seats |
| Alloy wheels |
| Wheel rim caps |
| third stop light |
| digital clock |
| fuel inertia switch system in case of accident & upside down |
| Anti -air pollution fuel filter (catalyst ,oxygen sensor) |
| Side protectors with chrome strips |
| Folding rear seat back |
| Painted front &rear bumper |
| new interior trim |
