pvc cat5e cat5 lan cable price lan cable standard

Brand:aa

Product detail:

pvc cat5e cat5 lan cable price lan cable standard



brief introduction:

Category 5  is a basic element of cate line of products designed for high speed networkd applications (eg.GigaEthernet 1000Base-T). 4 pair utp with different pitch for each pair. Small outside dameter, high flexibility. Available in 305m lengths and packed in carton boxes for easy transportation and laying in troughs. The cable does not feed fire and goes out when the source of fire is





  good sales       4*2*0.4mm copper coated alumium single shield  lan cable best quality and best service





2.construction



1)Conductor: you can see it in more detail in the above picture





* material:copper coated alumium



 * Conductor Diamter.: 0.4mm



 * Quantity:4 twisted pairs



 Blue/white-blue



 Green/white- green



 Orange/white-orange



 Brown/white-brown



 Insulation:



* material:high density polyethylene



* insulationDiameter:<=1.0mm



* Average thickness: 0.4325 mm



*  Minimum point thickness: 0.43mm















 4)sheath:



  * material:  PVC or LSZH



  * Nominal Diameter:<=5.50mm



  * Average thickness: 0.55mm



  * Minimum point thickness: 0.45mm















5)Mechanical Properties:



*Conductor insulation material: PE



*Cable jacket material: halogen-free, flame-retardant material



*Application area: dray as well as humid rooms



*Temperature (moved): 0°C to 50°C



*Operating temperature: -20°C to +60°C



*Min. bending radius for one-time bending: 4×O.D.(not less than 15 times of the outer diameter when the outer diameter is not more than 40mm and not less than 20 times of the outer diameter when the diameter larger than 40mm.)



*Min. bending radius during installation: 8×O.D.















We are manufacturer, warmly welcome your CUSTOM CABLE ASSEMBLY REQUEST















6)Cable assembly specification:







Conductor		Insulation		Core Number		Shielded		Jacket
AWG	Specification mm	Material	Thickness (NOM.mm)					Material	Thickness (NOM.mm)	OD (NOM.mm)
24	1/0.511	HD-PE	0.20	4P		PVC or LSZH		PVC or LSZH	0.55	5.5
26	1/0.404	HD-PE	0.20	4P		PVC or LSZH		PVC or LSZH	0.60	5.0















7).  Transmission Properties: ( at 20°C)
