Brand:aa
Product detail:
5.5Dbi Mobile Phone Antenna
ELECTRICAL SPECIFICATIONS | |
Frequency Range | 890-960 MHz/1710-1880MHz |
Impedance | 50 Ohm |
VSWR | less than 2 |
Gain | 5.5 dBi(Neglect the cable loss) |
Polarization | Vertical |
Radiation | Omni |
Lighting Protection | Direct Ground |
Maximum Power Input-watts | 50W |
MECHANICAL SPECIFICATIONS | |
Height | 315±1 mm |
Diameter of Chassis | Ø42 mm |
Coaxial Cable | RG58 |
Length of Cable | 5m±1% |
Termination | SMA-Male |
Marks: The cable length and the connector could be made per requirements. | |
