Product detail:
outdoor MIMO dual pol dish antenna for 5.8g wifi
Applications:
4.9/5.1GHz/5.5GHz/5.8GHz WLAN System Backhaul
Features:
High Gain, Large F/B ratio
High Precise Parabolic Dish
UV-Coated Aluminium Alloy
V/H Polarization is Compatible
Model | AC-D4958G32-09X2 |
Frequency Range | 4950-5850MHz |
Gain | 2×32dBi |
VSWR | ≤1.5Type;Max 2.0 |
Polarization | Vertical |
Horizontal Beam width | 3.5° |
Vertical Beam width | 3.5° |
Impedance | 50ohm |
Maximum Input Power | 100W |
Connector | 2×N Female |
Mechanical Specifications | |
Antenna Dimension | Ø900mm |
Weight | 12kg |
Mounting | Ø30~Ø50mm |
Rated Wind Velocity | 241 Km/h |
