Easy Installation Digital TV Antenna GKA60-W1

Model No.

GKA60-W1

Lobe

1

Reflector size

600×662mm

F/D

0.58

Elevation Alignment

5°~90°

Azimuth Alignment

0°~360°

Frequency

11.7~12.2  GHZ

Gain

≥35.6  dBi

Environment Temperature

-40~60°C

Environment Humidity

5~95%

Wind Scale(When dish fixed)

Working properly under 8 level wind

Precision decrease under 10 level wind

Survive under 12 level wind  (dish direction fixed)

A.Cutting Process
The rough shape of the satellite dish reflector is then marked by technicians on the reflector mould against  the unfolded steel sheet.


 B. Shaping Process
1.The cut-down rough shaped reflector plate is put into the pressing machine to shape the reflector by a particular mould. The reflector is formed into a parabolic shape.  2.The formed reflector is fed into the edge-cutting machine & drilling machine to cut the spare edge of the reflector & drill the reflector holes.


C.Powder Coating
We could print all kinds of dish and holders. The color could be chosen by you according to your quantities.

D.Finishing

Available sizes are 35cm, 45cm, 60cm, 75cm, 90cm, 120cm,135cm,150cm and 180cm

We supply satellite antenna with good quality but competitive price. Looking forward to your early enquiry
