Brand:aa
Product detail:
Cooper plated CD Welding Screws/ Weld Stud screw
Material Available: Carbon STEEL/ AL / Stainless steel/ Copper/Bronze.
Plating: Copper plated/ Cleaned
Size : M3-M12
Length: 5-200MM
Standard: ISO13918/DIN32501
Threads: Metric/SAE/Imperial
Stocking: Large-Stocking System, Low MOQ.
RoHS √
We accept special sizes and producing as per your drawing/Print.
The Production;:
The CD Welding Studs are made by Cold Forming / Truning/Lathing Technical.
1.For Flanged Studs, By Cold Forming Technical.(Making the Flange an the Welding Point )
2. For Non-Flanged Studs, Cold Forming 1st making the "Weld Point" and "Flanges", then Turning/Lathing CNC to cut off the Flanges. Or use directly Turning/Lathing to make the Weld Point. and then Threaded.
The Process;
1. Stud against the work plate
2. Stored energy discharged through special weld "timing" tip; stud starts downward
3. Stud forced into molten metal
4. Metal solidifies; weld is completed in a split secon
Type of Material;
| Materrial | Carbon STEEL | STAINLESS STEEL |
| C-0.20%Max P-0.04% Max | AISI 304 Std. | |
| Mn-0.90%max S-0.05%max | Other grade available upon request | |
| Mechanical Properties | Tensil 60,000 psi (min.) Yiled 50,000 si (min.) | Tensil 85,000 psi (min.) Yiled 40,000 si (min.) |
| PLATING | Copper plating is standard | Does not apply to Stainless |
| Annealed | Studs are annealed where required | Studs are annealed where required |
| Material | ALUMINUM | BRASS |
| Alloy 1100 & 5000 Series | Alloy (lead free) 70 - 30 std. | |
| Other alloys available upon request | Other alloys available upon request | |
| MECHANICAL PROPERTIES | Values for various alloys available upon request | Tensil 70,000 psi (min.) Yiled 50,000 si (min.) |
Capacitor Discharge (CD) Stud Welding
Advantages of CD
1.Welding to thin and sheet metal grade material
2.No reverse side marking
3.Up to 3/8" diameter fasteners
4.Only 115 volt power required
5.Up to 20 welds per minute
6.Welded metal fastening of dissimilar metals
Weldability; (More info. pls see ISO 14555.)
Only weldable materials shall be used for studs.
Non-alloyed steel studs are weldable if the hardness in crease is low. In general this is the case when the carbon content is
≤0.20%.Fee-cutting steel studs are generally not weldable.Killed materials shall be used.
Austenitic Stainless steel studs are generally weldable.Fee-cutting steel studs are generally not weldable.
Durability;
The durability of studs is dependent on their use and environmental exposure to which they are subject.
The mechanical durability of studs is assured for a reasonable economic working life if the studs comply with
the requriements of this International Standard 13918.
Size Ref. Mertic and SAE/Imperial sizes;
/ PT ,IT Type
PT TYPE
IT TYPE
Each Size can be reach a Length of 200mm. Pls contact us for Extra Long Weld Stud.
CD Stud Types*: (Not all available styles shown, for SAE /Imperial Sizes please contact us ,
we would reply you within 24 hrs..)
To Reudce,Reuse&Recycle to GREEN Our World.
Cycle-Usage of the Water.Bring as less harm as we can to our Earth.
Our Sewage treatment systems;
About Us:
Gaungzhou ShengFeng Hardware Co.,LTD.
We are Weld Stud manufactures and distributes a complete line of stud welding products. We are always fully stocked with many standard sizes of weld studs ( CD and ARC ,short cycle Weld Stud,), Weld Nuts(Hex/Square ),Rivets(Blind Rivet/Solid Rivet),Rivet Nuts and PEM Clinching Fasteners(PEM Clinching Stud/Nut ,Standoffs).
We now service for GM ShangHai,GuangZhou Toyota,HYUNDAI,NISSAN Zhengzhou.
SIEMENS,WHIRLPOOL,MCLI,SAMSUNG,Huawei,ZTE.
Exportting Mainly to EU,SOUTH/NORTH AMERICA,Rest to Middle East and Africa.
We believe Service that is second to none is always provided at GZSF Hardware Co Ltd. we Deliver our promise of great service ,we have been dedicated to providing our customers with quality products, service, and on-time deliveries.
Give us a call or email to see what a difference our personalized, professional service can do for you. We guarantee that we will exceed your expectations!
