Brand:aa
Product detail:
Scope of application for CVWU8600,Large Venue high lumen projector
1.outdoor advertising display
2.large-screen wall splicing
3.large cinema/theatre
4.Bars, KTV night clubs, concerts and churches
5.Daytime education (big multimedia classroom)
6.daytime company or business multi-media presentation(conference)
7.Training course, Houtdoor show projector
8.other situation need huge projection size enough brightness high lumens project projector
Technical parameters for CVWU8600 Large Venue high lumen projector
| Model Name | CVX8400,XGA | CVW8500,WXGA720P | CVWU8600,WUXGA |
| Display Technology: | 3 LCD Panels x 0.79" Policilicon | 3 LCD Panels x 0.75" Policilicon | 3 LCD Panels x 0.76" Policilicon |
| Physicial Resolution: | XGA (1024 x 768 Pixels) | WXGA /1280 x 800 Pixels | WUXGA/1920×1200 Pixels |
| Maximum Resolution: | Full HD (1920 x 1200 Pixels) | Support To 3200 x 1200 Pixels | |
| True brightness: (STD/ECO) | 10,000 ANSI Lumens (Market) 8,000 ANSI Lumens (std) | 10,000 ANSI Lumens (Market) 8,000 ANSI Lumens (std) | 10,000 ANSI Lumens (Market) 8,000 ANSI Lumens (std) |
| Contrast Ratio: | 4,000:1 (Full On/Full Off,Dynamic Contrast) | ||
| Aspect Ratio: | 4:3 Native, 16:9 Compatible | ||
| Displayable Colors: | 1.07 billion,10 bit color deep | ||
| Uniformity: | 95% | ||
| Projection Method: | Front, Rear, Ceiling Mount, Table Top;Projection Image support horizontal and vertical flip. | ||
| Keystone Correction: | ±40° Vertical,Automatic keystone correction | ||
| 3D: | support inactive 3D Red-blue, Red-green Film Source.With the 3D image noise reduction | ||
| Computer Compatibility: | IBM PC and Compatibles, Apple Macintosh, iMac, and VESA Standards 1080p (1,920x1,080), WSXGA+ (1,680 x 1,050)WXGA+ (1,440 x 900), WXGA (1,280 x 800, 1,280 x 768), UXGA (1,600 x 1,200), SXGA+ (1,400 x 1,050), SXGA (1,280 x 1,024),XGA (1,024 x 768), SVGA (800 x 600), VGA (640 x 480) | ||
| Horizontal Scan Rate: | 15 - 150 kHz (Depending on Resolution) | ||
| Vertical Refresh Rate: | 48 - 190 Hz (Depending on Resolution) | ||
| Video Compatibility: | NTSC , PAL, SECAM,HDTV (720p, 1080i, 1080P),EDTV (480p, 576p),SDTV (480i, 576i) | ||
| Standard Fixed lens: | 1:1.6X, F=1.7~2.2, f=22~35mm, 1/2x1/2~4x4 ; Digital Zoom/Focus, Lens can be replaced, OneTouch change Lens | ||
| Lens Shift H / V: | L/R±10% (Powered) / U/D ±50% (Powered) | ||
| Throw Ratio/Image Size: | 100" at 2.6m / 32"~5 00" | ||
| Projection Distance: | 0.8M~17.3M (Lens can be replaced,Depending on lens) | ||
| Lamp &Lamp Life:: | 330W USHIO High-Pressure mercury lamp; 4000 / 6000 Hours (Normal/Economy Mode) | ||
| Computer : | * 1 x VGA / Component Input * 1 x VGA / Component Output, | ||
| Video: | * 1 x YPbPr component video * 1 x S-video (4-pin mini DIN) * 1 x Video (YPbPr/CbCr) * 1 x HDMI 1.3, * 1 x CVBS | ||
| Aduio: | * Dual channel 2 x 3W | ||
| Control: | * 1 x RS232; * 1 x RJ45(Network) | ||
| Cable: | 1.5 m VGA Cable,1.5 m Power Cable,1.5 three-color audio and video cable | ||
| Other accessories: | Remote control, Product Manuals & Instructions (CD-ROM) | ||
| Lens cover, warranty card, certificate, etc. | |||
| Optional Accessories: | Replacement Lamp, Remote, Flight Case | ||
| Noise Level: | <38dB@ 27 Degrees Celsius | ||
| OSD User Controls : | 18 Languages; Other LanguagesCan Be Customized | ||
| Dimensions (W x H x D): | 535 mm x 390 mm x 190 mm | ||
| Weight: | 10.8 kg only Projector, 15 kg with Packing | ||
| Power Supply: | AC Input 100-240 V, 50-60Hz, Auto-Switching | ||
| Power Consumption: | 490 Watts (Bright), <5Watt (Standby) | ||
| Operating Temperature: | 0 - 40C / 32 - 104F | ||
| Operating Humidity: | 20 - 90% RH | ||
| Storage conditions: | 20 - 90% RH | ||
Outstanding features for CVWU8600 high lumen projector
1, Perfect Image quality by "BrightEra" 3LCD Panels
2,Newly adopted USHIO 330W lamp brings super effects of high brightness and contrast ratio along with extended lamp life
(6000H under eco mode).
3,Aeolus cooling system
The cooling efficiency is greatly elevated by 50%, which helps to extend the projector life.
4,High altitude mode
6 fans are installed for the heat generating DMD and lamp to ensure stable operation especially in high altitude areas above
3000 meters and southern areas of high humidity and temperature.
5,High adjustable contrast ratio brings super visual effects of sharpness and high definition.
6,New design of lamp shield prevents explosion shatters
The shield holds the lamp by 3 sides preventing internal damage braught by lamp explosion as well as physical injury to
people nearby. In addition, the lamp life is greatly extended as the metal shield helps to cool down the lamp.
7,Customized startup logo
Users can select pictures they like or the enterprise’s logo as startup screen.
8,Four auto functions
Auto reverse: with the projector suspending from the ceiling, the image will reverse automatically.
Auto turn off: with input source undetected for a certain period, the projector turns off automatically.
Auto synchronization: relock current input source.
Auto Input Signal Search: automatically search and lock the input signal.
9,Mutiple lenses options for diferent venues
Push the button, rotate the lens and it is goes off directly from the projector, easy and swift for lens replacing
Optional wide-angle and telephoto lenses .
10,Fine and closely woven dust-proof filter
The filter embedded at the side of the projector protects the inner optical system from the erosion of dust and ensures stable
operation.
11,360° projection for multi-media scenarios
WU8600 is able to project 360° vertically which is applied to muti-media scenarios.
12,Prioritized LAN network control
Through the LAN management and control, the user can easily operate every one of or some of projectors in the system
formed by connecting two or more units together.
13,Anti-theft design for better security
6mm anti-theft lever prevents your projector from being stolen and keeps it safe and sound.
14,Motored vertical and horizontal lens shift
Motored lens and focus functionalities are incorporated in LX8000 series. Vertical and horizontal image shift can be easily
carried out by motored lens instead of moving the projector manually.
Zoom in and out of the image can be easily carried out by remote control even if the projector is installed extemely high.
Motored zoom and focus for fine tune and remote control: even installed way out of reach, the projector is able to be operated
for adjustments in distance.
Lens shift: vetical(+/=50%)and horizontal (+/=10% max) shifts make operation directly visible for installation on site.
15,Adjustable cooling time, this newly developed technology embedded realizes the setting of cooling time
arranging from 3 minutes to 1 minute according to the user’s demands.
16,By embedded multi-direction infra receiver, all operations can be carried out by remote control. You can easily control the
screen only by the compact remote control.
17.Multiple connectivities
BNC is suitable for long distance stable signal transmission, a perfect match with top survailance and acoustic devices.
Component terminals are designed for business occasions. Compatibility with YPbPr input and output makes home cinema
and entertainment easily available.
Through the port, network operation and control is conveniently managed. A computer is able to control all the projectors
within the LAN, only if the user enters the corresponding IP in IE address bar.
HDMI, the best choice for film display, can transimit audio and vedio signals without compression.
Coolview CVWU8600series high lumen projector optional lens:
Coolview CVWU8600 high lumen projector after-sale service:
1. 5 years warranty and lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance
manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
