NMRV030 and NMRV040 Ratio:1:300-1:5000 Aluminium Double Worm Reducer Gearbox

Brand:aa

Product detail:

Aluminium Double Worm Reducer Gearbox





1) With excellent quality



(2) Reasonableprice



(3) Promise todelivery on time



(4) Large outputtorque



(5) Safe,reliable, economical and durable



(6) Stabletransmission, quiet operation



(7) Highheat-radiating efficiency, high carrying ability



(8) Certificate ofquality: ISO9001:2008



(9) Every productmust be tested before sending





  Aluminium Double Worm Reducer Gearbox    General Technical data





Model	Shaft Dia.	Center Height	Power	Ratio	Permitted torque	Weight
	Hollow	(mm)	(kw)		(Nm)	(KGS)
NMRV30	25k6	90h13	0.09~0.3	7.5~100	22	1.5
NMRV40	30k6	115h13	0.12~0.5	7.5~100	55	2.5
NMRV50	35k6	115h13	0.18~0.7	7.5~100	120	4
NMRV63	35k6	130h13	0.37~1.5	7.5~100	175	6.2
NMRV75	40k6	140h13	0.55~3	7.5~100	280	9
NMRV90	50k6	180h13	0.75~4	7.5~100	425	13
NMRV110	60m6	225h13	1.1~5.5	7.5~100	585	43
NMRV130	70m6	250h13	1.5~7.5	7.5~100	850	60
Remark: the weight without motor
