Supply YOXIIZ Constant Fluid Coupler

Brand:aa

Product detail:

YOXIIZ Constant Fluid Coupler

Specifications



1.Range of Power transmission: 0.05kw to 2360kw

2.Efficiency: 0.96



1. Features:

1.The effective start of the decrease in the impact, vibration, thereby protecting motor.

2.Effective overload protection, to protect the motor and machine work. Reduce mechanical damage.

3.In multi-drive system, effectively balance the electrical load.

4.The start-up can improve the electrical capacity to shorten the motor start-up time, reduce the impact grid.



2. Usage:

Mainly used in the mining, metallurgical, cement, chemicals, construction, building materials, electric power, telecommunications, textiles, and transportation departments.

Such as:

Conveyor: Belt conveyor.AFC conveyor.Chain conveyor.Screw conveyor.



Pump: Water pump, oil pump, slush pump,etc



Fan: Draft fan,,fanner, boiler fan,etc



Excavator: Bucket excavator. Bucket wheel excavators.Bucket wheel stacker reclaimer.

Crane: Tower crane.Gantry crane.Bridge crane.



Others: Various elevators.Coal plough.Ball mill.Crusher.Recreation machine.



Blender equipment.Centrifuger.Washer.Leather-making machine.machine for



recreation park mixer wire drawing machine.Extruder,dregs crusher of boiler.



Plastic feeder.Rubber smelling machine.etc.



3. The Drawing



4.The Parameters

 YOXIIZ



TYPE	Input Speed (r/min)	Range of transmitted Power (kw)	Dimen- sions		Max. input Bore diameter /length (d1/L1)	Max output Bore diameter /length (d2/L2)	Volume Of Filling Oil(L)		Weight (kg)
			D	A
YOXⅡZ400	1000	8-18.5	Φ465	556	Φ65/140	Φ65/140	5.2	10.4	115
	1500	28-48
YOXⅡZ450	1000	15-30	Φ520	580	Φ75/140	Φ75/140	7.5	15	128
	1500	50-90
YOXⅡZ500	1000	25-50	Φ582	664	Φ90/170	Φ90/170	10.3	20.5	156
	1500	68-144
YOXⅡZ560	1000	40-80	Φ634	736	Φ100/210	Φ100/210	13.2	26.4	205
	1500	120-270
YOXⅡZ600	1000	60-115	Φ695	790	Φ110/210	Φ110/210	16.8	33.6	260
	1500	200-360
YOXⅡZ650	1000	90-176	Φ760	829	Φ120/210	Φ120/210	24	48	386
	1500	260-480
YOXⅡZ750	1000	170-330	Φ860	940	Φ130/210	Φ130/210	34	68	488
	1500	380-760
YOXⅡZ875	750	140-280	Φ992	1040	Φ140/250	Φ140/250	56	112	655
	1000	330-620



5.The Product:







Notes:

1) Model YOXIIZ  is  with brake wheel,is used where brake is needed,It is drivenby  external wheel with compact structure.

2) All the sizes are uniformed in the whole trade.

3) The sizes of break wheel may be consulted separately.
