Submersible electric motor irrigation pump

Brand:aa

Product detail:

Submersible irrigation  pump



Introduction





1. Widely used for agricultural irrigation and drainage, garden irrigation, fountain water supply, well pumping,industrial and mining enterprises water supply and drainage, etc

2. The motor is filled with oil inside, water outside won't inflow the motor easily, the oil will conduct the internal motor heat rapidly, cooling effect is better, add motor's overlaod capacity, .

3. The pump bearing is dipped in oil, the lubricating and cooling is guaranteed, so the bearing life is longer than other submersible motor pump.

4. Made up of water pump, seal and motor ,joins pump body and motor into one.

5. Have no use for pilotage, easy installation, convenient maintainance.

6. Double-end seal, electrical protection, compact structure







Working condition





1. Medium temperature : less than 40 °C
2. Ambient  temperature up to  40 °C

3. Solid  impurity in the volume no more than 0.1%, particle size less than 0.2mm



4. The using lift can not be too low , below the stipulated 80% lift easily lead  to thermal protectors, so that pump to stop running and some may even cause electrical damage.

5. The  diving depth must be less than 5m .

6. PH value of water 6.5~8.5

7. Power supply:   Single phase--------220 V+-10%, 50 HZ



                              Three  phase--------380 V+-10%



                              Other power of motor , can customize





Model significance and specification





Item	Inlet/outlet Dia.(mm)	Item	Inlet/outlet Dia.(mm)	Middle sized for ordinary mine use
				Item	Diameter	Item	Diameter	Item	Diameter
QY15-26-2.2	50	QY25-42-5.5	65	QY10-86/3-3.5	50	QY30-210/6-30	65	QY80-150/3-55	80
QY25-17-2.2	65	QY40-26-5.5	80	QY10-110/4-7.5		QY40-58/2-11	80	QY80-180/4-60
QY40-16-3	80	QY65-18-5.5	100	QY10-143/5-9.2		QY40-87/3-15		QY80-200/4-75
QY65-7-2.2	100	QY160-8-5.5	150	QY10-165/6-11		QY40-120/4-22		QY100-72/2-30	100
QY100-4.5-2.2	150	QY250-5-5.5	200	QY10-192/7-13		QY40-220/5-37		QY100-90/3-37
QY15-36-3	50	QY25-52-7.5	65	QY10-220/8-15		QY40-260/6-45		QY100-110/3-45
QY25-26-3	65	QY40-38-7.5	80	QY20-65/3-5.5	65	QY65-42/2-11	100	QY100-135/4-55
QY40-19-3	80	QY65-25-7.5	100	QY20-87/4-7.5		QY65-60/3-15		QY100-150/4-60
QY65-10-3	100	QY200-9.5-7.5	150	QY20-110/5-9.2		QY65-70/4-18.5		QY160-48/2-30	150
QY160-40-3	150	QY250-7-7.5	200	QY20-130/6-11		QY65-87/4-22		QY160-70/3-45
QY12.5-50-4	50	QY10-51/3-3	50	QY20-150/7-13		QY65-100/4-30		QY160-95/4-60
QY25-32-4	65	QY10-72/4-4	50	QY20-170/8-15		QY65-130/2-37
QY40-22-4	80	QY10-60/2-4	50	QY30-80/2-11		QY65-200/3-55
QY65-14-4	100	QY100-2511	100	QY30-120/3-15		QY65-260/4-75
QY200-4.5-4	150	QY160-15-11	150	QY30-135/4-18.5		QY80-90/2-30	80
QY250-4-4	200	QY350-7-11	120	QY30-160/4-22		QY80-135/3-45







Longitudinal profile









 Product pictures
