Manual Lifting Pneumatic Ink Mixer

Brand:aa

Product detail:

Manual Lifting Pneumatic Mixer (EA230)



Description

EA230 manual lifting pneumatic mixer is a horizontal plate moving up and down on a single pillar to complete lifting, fixing with screws and barrels fixed by clip during the mixing process to achieve the situation of displacement. Air motor inlet valve controls the speed of air motor speed to control mixer’s speed.



Application range: mixing paint, ink, oils, resins, asphalt, molasses, liquid medicines, motor oil, paints, dyes and other materials.



Basic parameters:

Motor Type : EMH010 (according to viscosity and volume to option)

Rated Power : 0.1HP (according to viscosity and volume to option)

Rated air pressure : 0.6 MP

Rated speed : 0-1100 switch (can be variable speed)

Rated torque : 0.64N.m

Rated Air Consumption : 180L/min

Impeller : A ~ S (according to viscosity and volume to option)

Motor Weight : 1.8kg

Shaft length : Φ12 * 230mm  (according to viscosity and volume to option)



Pneumatic motor features

1. Not heated with long time working, long performance life, explosion-proof, not effected by high temperature and shake.

2. Speed stepless adjustment; adjust air pressure to control the rotate speed.

3. Can be worked with full with lower temperature.

4. Load overweight or stuck when the motor does not heat damage, and can load start.

5. Humid or dusty places can still be used normally.



Optional air motor suggestions

The case of certain horsepower, torque, slow speed applications that require large load; torque is great for a small speed fast rotation.
