Diamond Core Drill Bit Segment For Concrete Drilling

Brand:aa

Product detail:

 Professional  Diamond Core  Drill  Bit Segment For  Concrete  Drilling

Usage and Features :
1. Used for the core bits  from diameter 10mm to 350mm. the drilling length:350/450mm
2. Applicable for reinforced concrete  drilling



3. Characterized by high sharpness and long life span.
4. We can design the diamond segments according to stone feature, such as hard, medium-hard or soft.
5.Market approved quality, all of our products have been strictly tested before access to market,



Any other specification are available. welcome to contract us .



Outer Diameter	Segmnet Dimension	Teeth No.	Application
32mm	16*4.0* 10mm	4pcs	For drill  concrete  reinforced  concrete
37mm	16*4.0* 10mm	5pcs
40mm	16*4.0* 10mm	5pcs
42mm	16*4.0* 10mm	5pcs
47mm	16*4.0* 10mm	6pcs
52mm	16*4.0* 10mm	7pcs
56mm	16*4.0* 10mm	8pcs
63mm	24*4.5* 10mm	6pcs
76mm	24*4.5* 10mm	8pcs
83mm	24*4.5* 10mm	8pcs
90mm	24*4.5* 10mm	9pcs
102mm	24*4.5* 10mm	9pcs
108mm	24*4.5* 10mm	10pcs
120mm	24*4.5* 10mm	11pcs
132mm	24*4.5* 10mm	12pcs
160mm	24*5.0* 10mm	13pcs
182mm	24*5.0* 10mm	14pcs
202mm	24*5.0* 10mm	16pcs
250mm	24*5.0* 10mm	17pcs
300mm	24*5.0* 10mm	18pcs
350mm	24*5.0* 10mm	20pcs
