ORBITA electric card lock system( keep the mortise and carpentry,save your door)

Brand:aa

Product detail:

ORBITA electric card lock system(keep the mortise and carpentry,save your door)



Replace your old mechanical lock with our electronic lock,

Keep your mortise and carpentry,save your door.



Main Features:

Weight:2.5 kgs/pc

280mm*38mm*20mm

Static Load<15Ua

Working Load:200Ma-400Ma

Humidity:20%-80%

Working tempreture:-50°C-80°C

Stainless steel Material, moisture proof, fire retardant

Satin Chrome, coating lasting 10 years

European Standard mortise 72mm/85mm hole distance

Mortise thickness 18mm,strike thickness 22mm

No electronic inside mortise.

Inside Dead Bolt.

Temic E5557 card,100,000 times life span, high security,compatible with Energy Saver.

Override Computer Key for Emergency use, individual/master cylinder

Personalized Locking System

Step by step installation software, easy operation. OEM locking system available.

Classified Access Authorization for safety management.

General master card, building master card, floor master card, guest card

All card with validity, guest card expires automatically at default check out date and time.

Lost guest card suspension simply by issuing a new guest card or Cancel card.

Multiple operators with different card issuing authorization

Lock operation record printable. 240 pcs or more

Receptionist card issuing records printable

Power:3 pcs #7 Alkaline battery. 12 months’ duration

Low Battery Voltage warning. (Lower than 3.6 V.)

Self Error detecting by LED and “beep”.

Wireless stand alone lock realizes 95% of on line lock function.

Passage function available

Swimming Pool/Sauna Room/Tennis court/Gym access lock function

Interface with most of the PMS system (Fidelio Registered)

CE FCC



Lock Indication Symbols

No.	Status	Beep Indication	LED indication(flash)
1	Correct	1	green LED, 1
2	Slant Latches get Stuck	Continuous	Red LED keeps flashing
3	Error	2	Red LED 3
4	Clear Authorization	1 Long	Green LED 1
5	Wrong Area	3	Yellow LED 2
6	Wrong time	3	Yellow LED 3
7	Card Suspending Error	3	Yellow LED 4
8	Illegal Card	4	Yellow LED 3
9	Illegal card	4	Yellow LED 4
10	Clock card over time	4	Red LED
11	Deadlocked	2	Red LED
12	Non Access Setting	5	Red LED
13	Cancel	3	Red LED
