Brand:aa
Product detail:
ORBITA card reader electronic lock with FREE SOFTWARE ( Fidelio regestered)
1. hotel card lock with led display Data sheet
Item# | Description | Technical Parameters |
1 | Power: | 6V AA alkaline batteries, |
2 | Static Electric Current: | Static Load<10Ua,Working Load: 100Ma-150Ma |
3 | Working Electric Current: | 100-300mA |
4 | Card type | Temic 5557 card |
5 | Battery Life: | 18 months’ duration |
6 | Lock operation records | 240pcs |
7 | Insert Reliability: | No mistake even inserted continuously 2000 times |
8 | Insert Guarantee: | Still work well after inserting any illegal card |
9 | Low Voltage Warning: | low Battery Voltage warning. (Lower than 3.5 V) |
10 | mortise | ANSI Standard mortise/Euro standard |
11 | Humidity | 20%-90% |
12 | Working tempreture | -50°C-80°C |
13 | Suitable door | Wooden door, fire-proof door, metal door and so on. |
2. How ORBITA hotel card lock system works?
Our hotel locking system consists of following:
- PC (usually located on the reception desk of hotel lobby)
- Hotel lock management software+Encoder (How the cards are issued)
- Hotel card lock (Installed on the hotel room door)
- Cards (The keycard to open doors)
3. Card function:
-Guest card:Reception complete program Guest card by give a begin and expiry date for a room(rooms).Guest access room by -read this card on lock
-Master card:Hold by housekeeping to access to all rooms of hotels
-Floor card: old by clean staff to enter the rooms in one floor.
-Building card: Hold by manager to enter the rooms in one building
-Passage card:Once this card been read on one door,this door could be acceess by without reading keycard
4. Lock Indication Symbols
No. | Status | Beep Indication | LED indication(flash) |
1 | Correct | 1 | green LED, 1 |
2 | Slant Latches get Stuck | Continuous | Red LED keeps flashing |
3 | Error | 2 | Red LED 3 |
4 | Clear Authorization | 1 Long | Green LED 1 |
5 | Wrong Area | 3 | Yellow LED 2 |
6 | Wrong time | 3 | Yellow LED 3 |
7 | Card Suspending Error | 3 | Yellow LED 4 |
8 | Illegal Card | 4 | Yellow LED 3 |
9 | Illegal card | 4 | Yellow LED 4 |
10 | Clock card over time | 4 | Red LED |
11 | Deadlocked | 2 | Red LED |
12 | Non Access Setting | 5 | Red LED |
13 | Cancel | 3 | Red LED |
