JK series high speed winch use for crane and installation industry

Brand:aa

Product detail:



JK series high speed winch use for crane and installation industry from Xinxiang HY Crane manufacturer





This series high speed winches is manufactured with a highly durable steel structure and especially designed to meet the lifting requirements for installation industry. High speed is the main advantagement that can highly improve your working efficiency where continuous usage is necessary.







JK series high speed winch use for crane and installation industry feature

1.Final Drives gears are made with heat-treated carbon steel offering greater strength.

2.Precision needle bearing used in high-load areas offering lower friction level and longer life.

3.High impact case providing weather resistance and protection for internal components.

4.Durable hook safety snap keeping the loads attached.





Technical parameter

JK series high speed winch use for crane and installation industry

Items	Rated load	Rated Speed	Rope Capacity	Rope Dia.	Motor Type	Power	Dimension	Weight
	(KN)	(m/min)	(m)	(mm)		(Kw)	(mm)	(kg)
JK0.5	5	22	190	7.7	Y100L2-4	3	620*701*417	200
JK1	10	22	100	9.3	Y112M-4	4	620*701*417	300
JK1.6	16	24	150	12.5	Y132S-4	5.5	945*996*570	500
JK2	20	24	150	13	Y132M-4	7.5	945*996*570	550
JK3.2	32	25	290	15.5	YZR180L-6	15	1325*1335*840	1011
JK3.2B	32	30	250	15.5	YZR200L-6	22	1900*1738*985	1500
JK5	50	30	300	21.5	YZR225M-6	30	1900*1620*985	2050
JK5B	50	25	210	21.5	YZR225M-8	22	2250*200*1300	2264
JK8	80	25	160	26	YZR280S-8	45	1533*1985*1045	3000
JK10	100	30	300	30	YZR315S-8	55	2250*2500*1300	5100







 JK series high speed winch use for crane and installation industry



























1,15 months warranty for whole machines.



2,Providing free quick-wear part.



3,Low charge for continue maintenance when warranty is expired.



4,Exclusive engineer support at any time.



5,We can provide free training to end-users.
