Medical Waste Incinerator-HS75
hospital incinerator according the booming and developing of china city fast growing and large quantity garbage generated in the same time.The incinerator can be used for bus station,harbour,airport, people square and hospital etc.,the incinerator used to combustion waste plastic, rubber, film, leather, resin, paper, hospital garbage and various toxic and harmful waste.It is easy to operating and without black smoke, no odour, fast combustion and better efficient. The incinerator can be added with residual heat utilization system and automatic material loading system depend on user requirement, it can be save energy. The incinerator take less land, with less cost, less problems and easy maintenance.
1.Furnace type: vertical static grate
2.Fuel type:diesel or gas
3.Ignition: automatic electronic
4.Ash picker: slag down to the slag chamber, the flyash collected by baghouse.
5.pressure in furance:-50Pa~-100Pa
6.designed thermal value: 6300KJ ~12500KJ designed thermal value
7.flue gas disposal: dry absorbing, spray water cooling and baghouse dedusting.
8.combustion temperature: 800-850 degree,second combustion chamber temperature 1100 degree.
9.Flue gas detain time: 2 second
10.Full automatic control system, designed with interlock, trouble alarm system.
11.Flue gas emission depend on GB18484-2001 < Pollution control standard for hazardous wastes incineration>
Type | HS-50 | HS-75 | HS-100 | HS-150 | HS-200 | HS-260 | HS-320 | |
Capacity (KG/h) | 50-60 | 70-80 | 100-120 | 150-170 | 200-220 | 260-2800 | 320-350 | |
Volume (m3) | 1.2 | 1.8 | 2.4 | 3.6 | 4.8 | 6.2 | 7.6 | |
Steam (KG/h) | 130 | 200 | 260 | 400 | 500 | 700 | 900 | |
Burner | Power(Kcal/h) | 18×103 | 18×103 | 22×103 | 26×103 | 30×103 | 30×103 | 30×103 |
Fuel (KG/h) | 0~1.99 | 0~1.99 | 0~2.44 | 0~2.89 | 0~3.34 | 0~3.34 | 0~3.34 | |
