Double Stage High Vacuum Transformer Oil Purifier Factory

Brand:aa

Product detail:

ZLA Double Stage High Vacuum Transformer  Purification Machine



ZLA can purify all kinds of insulating oil, e.g.: transformer oil, switch oil, mutual inductor oil, capacitor oil etc.

quickly remove water, particulate matter, gas, acid, free carbon, color and decrease dielectric loss

it can be customized according to customers' needs, such as:

1) ZLA-Ex: used in flammable and explosive work condition.

2) ZLA-F (closed type): used in wet and dusty work condition.

3) ZLA-X : adopt stainless steel, it's erosion-proof and acid-proof, can be used in food industry and other chemical industry.



Application

    ZLA series is widely used in purification of various types of insulating oil , especially the deep purification treatment of high-voltage transformer oil , high-grade new oil and imported oil . While keeping all the advantages of single stage vacuum oil purifier , ZLA has additional roots vacuum pressurizing system , second time highly vacuum separation system . It can be used for field operation in over 110KV transformer station , especially in high-latitude areas.



Techinical Parameter

Parameter		Unit	ZLA-30	ZLA-50	ZLA-80	ZLA-100	ZLA-150	ZLA-200	ZLA-300
Capacity		L/min	30	50	80	100	150	200	300
Vacuum Degree		MPa	-0.08 ~ -0.099
Working Pressure		MPa	≤0.5
Working Temperature		.C	20 ~ 80
Working Noise		dB(A)	68	70	72	75	78	80	82
Heating Power		KW	30	36	48	60	90	120	150
Total Power		KW	34	40	54	66	98	130	165
Inlet (Outlet) Diameter		mm	Φ25	Φ32	Φ32	Φ42	Φ48	Φ60	Φ76
Net Weight		kg	650	850	900	1100	1400	1800	2000
Overall Dimensions	L	mm	1200	125	1500	1600	1700	1750	1800
	W	mm	920	950	1100	1150	1200	1250	1300
	H	mm	1450	1500	1700	1800	1800	1900	2000
Breakdown voltage			≥75 KV  (GB/T 507)
Content of water			≤3 ppm  (GB/T 7600)
Content of gas			≤0.1%  (DL/T 423)
Content of granule			≤NAS 6  (DL/T 432)
Flash Point			≥ 135 .C
Content of Impurities			≤3μm (No free carbon)
