quartz bubble tube diffuser

Brand:aa

Product detail:





1:Name:   fine/coarse bubble tube diffuser

2:Material:  Quartz

           The quartz diffusers are composed of pure quartz sand bonded with a glass binder to form a stable,mechanically strong porous element.Due to the exactly defined quartz grain size distribution and a well controlled production method,the quartz diffuser cylinders and discs have a remarkably homogeneous porous structure.

This results in a very uniform air distribution and bubble release.

3: Physical Properties:

	Unit
color		white
Porosity	%	30-35
Material density	g/cm³	1.6
Pore size	μm	70
Bending strength	Mpa	>12
Mohs' hardness	Scal	7
Max. temperature resistance1	oC	600
Operating pressure	Mpa	0.3
1Depending on operating conditions

 4:Chemical Resistance:

Quartz diffusers are resistant up to pH 9.5 against municipal waste water as well as against waste water from industrial sewage water plants. The diffusers have a good chemical resistance against most solvents, hydro carbons and acids.



(As end use conditions can vary,it is the users’ responsibility to verify compatibility with their specific use conditions.)



 5:Standard Dimensions:



Name	Item No.	Do/Di (mm)	Length (mm)
Bubble tube diffuser (quartz)	DQQT-diffuser-60/40	60/40	According to customer’s request.
	DQQT-diffuser-70/40	70/40
	Special dimensions and special products on request.



6:Applications:

The diffusers are mainly used for the aeration of waste water.

Fine bubble aeration       Fine bubble aeration for activated sludge processes for nitrification and C-            decomposition:

                                         > municipal waste water treatment plants;

                                         > industrial waste water treatment plants;

Coarse bubble aeration     Coarse bubble aeration of waste water in grit chambers and mixing:

                                            > waste water mixing avoiding sedimentation;

                                            > homogenization of waste water feed;

Further applications possible.



Note:As end use conditions can vary,it is the users’ responsibility to verify compatibility with their specific use conditions.
