Brand:aa

Product detail:

  Distillation oil equipment

the technical speciality:

No.	Items	Specifications
1	Equipment type	XHZT-5/1015/20/30/40/50 tons
2	Raw material	Tyre oil, plastic oil, waste engine oil, crude oil,oil sludge
3	Structure form	Horizontal
4	Capacity	5/10/15/20/30/40/50 tons/set
5	Working time	5-7days
6	Material of reactor	Q245R boiler plate
7	Thickness of reactor	14mm
8	Total power	1-2kw/h
9	Size of reactor	depends on your needs
10	Fuel	Coal or wood or oil
11	Workers	2-3 workers
12	Diesel	Get about 90% diesel oil over 200°C
13	Water vapor	1%
14	Oil  slag	9%

 Waste Oil Recycling Machine is mainly used to extract high quality oil from the used mineral oil.

 Comparing with the tube type model XHZTseries, the daily output of the series of model XHZT would slightly less than XHZT series. But it not needs to dehydrate first, the process of the dehydration and refining are in the same process in the furnaces. By means of oil-water seperator, the oil and water would be seperated and the extracting process goes on continuously





our main features



a. The complete set of unit produces no smoke and smell with favourable effects of

environmental protection.

b. The pressure release device operates through water circulation, which greatly im

proves the security of the system.

c. The release of pressure during the production dramatically increases the output

within certain time and meanwhile improves the quality of oil.

d. The heating system adopts hot air heating technology, which improves the safety

performance of production and heating efficiency.

e. High efficiency fuel gas heating system. When the heated gas reaches 150 during

refining, a large amount of gas will be generated: through methane to butane, which

cannot be liquefied under normal temperature. A large quantity of energy will be gen

erated after these gases fully burn within a specially designed gas burner. Then energ

y will be saved greatly.
