J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer

Brand:aa

Product detail:

  J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer

JP-600

Brief Introduction:

The J-Style Pedometers is the first J-Style device to help runners accurately track their pace and distance during a run. The unit features 3D Smart Sensor technology that makes tracking, pace, distance and calories burned accurate and reliable to help runners achieve their goals and go further.



1. Components of  J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer





2. Function of J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer





J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer
Item NO.	JP-600
Product name	J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer
1.Feature	1. Running pedometer with 3-dimensional acceleration sensors
	2. Running pedometer can measure your jogging and running activities
	3. Goal Setting function, you can set your target steps everyday(1,000 to 99,000 steps)
	4. Memory function to store and display results over the last 14 days
	5.Power save mode, when the product is idle for one minute the screen will shut-off
	6. Memory automatically resets at midnight each day -ready to go each morning
	7. Clock, with 24 hours time display of Pedometer Steps
	8. Battery lifespan indicator, warns you when you'll need to change your battery
2.Specification	1.Step counter (MAX.99999 steps)
	2. Distance counter(MAX.99.999 km or mile)
	3. Calorie consumption display(MAX.9999.9 kcal)
	4. walking Speed:0.00--99.99 km/hour
	5. Display training time(MAX.99H 59M)
	6. DC3V (CR2032)battery (lifetime:1 year for 10,000 steps one day)
3.MOQ	1,000 pieces
4.Payment terms	T/T,LC,Western Union,PayPal optional
5.Package method	PE bag,white box or gift box,then in a outer carton. Or per customer's requirements
6.Production time	Around 2-3working days for samples,20-25woking days for mass production
7.Loading port	Shenzhen
8.Personal Setting	1.Weight: 20 to 130kg
	2.Stride length: 30 to 120cm
	3.Time: 0.00 to 23.59 (24 hour display)
	4. Goal setting: 1,000 to 99,000 steps
	5. Date: Jan 1st 2012 to Dec 31st 2040





3. Specification of  J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer





4. Features: J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer



Pedometer Counter CE  specifications:

1.Pedometer Material: ABS

2.Battery:DC3V(CR2032)

   Lifetime:one year (according to 10,000 steps a day)

3.Dimension: 75 x 33.5 x 10.8 mm

4.Step accuracy: ±5% per month



Pedometer Counter CE   features:

1. Easy operate step counter

2. Extra large digital display
3. Durable construction

4. Outstanding accuracy
5. Delayed reset button
6. Secured battery



5. How to attach :  J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer



Note: To prevent the unit from dropping.We recommend that you use a cord to tie it to your belt.







6. How to replace the battery of  J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer







1.Open the back case.(Fit a coin into the groove to remove the cover.
2.Remove the worn battery.
3.Insert a new battery with the correct alignment of polarities.
4.Close the back case.
5.Initialize data with a stick.(Do not use a pen or easy broken stick.)





7. Precautions of 3D free pedometer

Your pedometer has small parts and is not intended for young children



Upon removing the battery, settings and stored results will be lost



Dispose of used batteries in accordance with local regulations for battery disposal. Individual results will vary; measurements may not be correctly registered by:







-- Walking excessively slow or by “quite walking”



-- While in a moving vehicle



-- Irregular motion or swinging of the activity monitor



-- Extreme impact: jumping, rope skipping, high impact running







8. Maintenance of 3D free pedometer

-- Clean with a soft dry cloth or a cloth moistened with water



-- Do not use alcohol, benzene, thinner or other harsh chemical



-- Do not submerge the activity monitor in any liquids



-- Remove the battery when not in use for long periods of time





9. More Pictures of  J-Style Multifunctional LCD Digital Display 3D Manual For CE Pedometer









 P









Certificate







10. Why choose Joint Chinese Group,Dream&Widen Co., Ltd?



Our R & D team:
- Technology support from Japan. Now 7 Japanese engineers work in our factory to provide us software programming and technology support.
- Over 15 Chinese engineers work together to realize a idea to a real product, responsible for such services like external industrial design, internal structure configuration, PCB layout and technique support during all process of ODM development process.

Our Facilities:
We have our all workshops for design to production, such as moulds making, plastic injection, CNC prototype making, Silk printing, Painting spray, SMT, Hardware making and final mass assembling line, which enable us to provide one-stop OEM & ODM services all in house.

Our Strategic Customer:
Thanks to our strong R&D team, our services are well received by such brand companies asYAMASA, CITIZEN, TANITA, SEIKO, A&D, etc.
