Brand:aa
Product detail:
3KW Wind Turbine for Home(HAWT)
Overview |
With a rotor diameter of 4.0m and a peak output of approximately 4000 watts the CAT-3KW Wind turbine generator is intended for the off-grid home market , telecommunication sites, and for rural electrification programs in developing countries. It is also a perfect upgrade system for current owners of solar-only off-grid systems.
Very quiet operation is achieved with advanced rotor design and an oversized alternator that reduces the rotor operating speed.
The CAT-3KW wind turbine generator is currently available as a 48/96/120/220/240VDC battery-charging system and on-grid system available too.
| 3kw Wind Turbine Generator - Recommend For |
- Household,garden
- Rural electrification programs.
- water pump <1kW,TV, Light, fan,
- Washing Machine, Fridge
- Electric Cooker
3kw Wind Turbine -- Installation |
The CAT-3KW wind turbine is offered with a tower in heights from 6m (20ft) to 20m (125ft). These kits are easy to install and offer customers a complete "ready to install" kit.
CAT-3KW wind turbine is offered with all the accessories for installation inclouding generator ,blades,tail,nose cone, controller,invertor ,tower. Bolts,cables,anchors etc.
But batteries suggest customer buy from local. Customers can choose buy any parts of the system.
3kw Wind Turbine -- Products details |
- Manufactured by: ZIBO CAT WIND GENERATOR CO.,LTD
- Quiet operation
- Lightweight; easy to install
- Energy in low wind
- Plug and play battery connection
- Integrated overcharge protection for peak power production
- LED communication
- For non-corrosive environments. 3-year warrany
3KW Wind Turbine Technical Parameter |
| CAT-3kw Wind Turbine Technical Parameter | |
| Blades rotor diameter | 4m ( 13.12 ft.) |
| Blade material and quantity | 3 Pcs / FRP made by hand |
| Rated power | 3000W |
| Max power | 4000W |
| Rated rotate speed | 320(r/min) |
| Start Torque | 2.5(N.M) |
| Generator Type | PMG AC Direct Drive |
| Optional Output Voltage(DC) | 48-240V |
| Start up wind speed | 3 m/s ( 6.72 mph) |
| Rated wind speed | 10m/s ( 22.4mph) |
| Working wind speed | 3-25m/s (6.72-56 mph) |
| MAX.Design wind speed | 50m/s (112mph) |
| Tower Height | 8m(26.24ft)higher available |
| Top Weight | 240kg |
| Controller | OFF-Grid Hybrid charging controller with 30% solar |
| Invertor | OFF-Grid Invertor Rating 3kva |
| Dump loader rating | 6000w |
| Protection method | Tail vane Autolean |
3KW Wind Turbine -- Accessories details |
Solar and wind hybrid charge Controller
Protection method : PWM+3Phase dump load
Pure sine wave invertor
| 3kw Wind Turbine - Option Tower |
We can supply guy wire tower , tilt -up tower for your option and if you want make tower from local ,we can give tower drawing .
A. Guy wire tower ≥8m
Easy Installation, cheaper, light but should need more space.
B. Tilt-up Free stand tower ≥8m
Easy installation, no need crane, save 50% cost of installation and maintanence
3kW wind +900W solar hybrid Generator System |
The Wind Turbine For Home use is often used in conjunction with solar panels to provide more reliable year-round energy supply.
Rated can connect 900w solar panels directly. More solar panels is also avaliable.
We can supply complete system with tower controller ,invertor ,dump load and battery bank, if any part you don't need ,please let me know.
CAT WIND TURBINE -- Certification |
| Packing and factory overview |
Remark |
- Optional by-pass function ensures the continuity and stability of system operation
- Optional wind turbine low-voltage charge function, making full use of low wind power
- Optional multiple control system function, real-time monitoring the multiple control system at the same time, with well-organized and exact monitoring interface
- Optional termperature compensate
- In order to serve our customers better. Our company can adjust parameters configuration according to customer’s requirement.
Trade term:
Minimum Order Quantity :1 set
Delivery time :7-15 days after received the deposit.
Payment : T/T 50% deposit and balance before delivery .
Package : ply wooden case
