45KW/56KVA Cummins engine Powered Generator set

Brand:aa

Product detail:

45KW/56KVA Cummins engine Powered Generator set

• Diesel generator features:
  • Prime power: 45kw/56kva
  • Standby power: 50kw/63kva
  • Voltage: 230/400V (adjustable)
  • Power factor: 0.8 (lagging)
  • Connect type: three-phase and four-wire
  • Insulation class: H/H
  • Protection grade: IP21-23
  • Consumption: 10.3 l/h diesel
  • Dimension: 1730*710*1225mm
  • Weight: 680 kg
• Diesel generator  features:
  • Voltage regulation: ≥ ±5%
  • Voltage regulation, stead state: ≥ ±1%
  • Sudden voltage warp (sudden reduce): ≤ +20%
  • Sudden voltage warp (sudden increase): ≤-15%
  • Voltage stable time (sudden reduce): ≤1.0s
  • Voltage stable time (sudden increase): ≤ 1.0s
  • Frequency regulation, stead state: ≤0.5%
  • Frequency waving: ≤ 0.5%
  • Frequency recovery time (sudden reduce): ≤ 1.0s
  • Frequency recovery time (sudden increase): ≤ 1.0s
• Engine features:
  • Engine brand: cummins
  • Engine type: in-line four-cycle and water cooled
  • Turbocharged and inter-cooler
  • Combustion type: direct injection
  • Model: 4BTA3.9-G2
  • Maximum power: 55kw
  • Bore and stroke: 102*120 mm
  • Coollant capacity: 20.0 L
  • Oil capacity: 11.0 L
• Standard accessories of emergency generator/standby power/diesel generator:
  • Standard control panel, exhaust silencer, flexible pipe, battery and battery cables, battery rack, operation manual and document
