Brand:aa
Product detail:
2kW wind generator for wind solar hybrid power system Specifications
Rated power 2000watts at wind speed of 9m/s(20mph)
Max power 3200watts at wind speed of 14m/s(31mph)
Cut in speed at 3m/s (6.7mph)
PMG wind generator
Voltage:48v/120v DC,AC110v/220v avail
Battery suggestion:12v 150AH/200AH/10PCS
2years warranty
Solar panel suggestion:1kw
Application:Home back up,remote place power supply, telecommunication , monitor station
Key Features
1.Light,smart,high efficiency with 7 National Patents
2.Lower noise and long service life with 2 SKF bearing in generator part
3.Multiple protection:mechanical furling,manual and electromagnetic braking
4.Airfoil design blades ,strictly tunnel and balance tested
5.Hot galvanizing and spray paining surface efficient to prevent the turbine from atmospheric,salt spray and aeolian erosion
6.UL and CE tested and certified,ISO standard
7.Guyed tower,free sanding tower ,optional
8.Can use wind solar hybrid system,solar and wind will charge the battery complementary ,suitable for the place wich wheather is changable and seasonal .
9.2000w wind generator can match with 1000w solar panel which total rated out put can be 3000w
10.Easy installation with guy tower and solar panel holder supplied.
Solar panel
Wind-solar hybrid controller
with the function of controlling wind and solar charge at the same time ,ensure the stoarge and output power reliable .
Rated power (W) | 2000 |
Maximum output power (W) | 3200 |
Battery bank voltage (VDC) | 120 |
Cut-in wind speed (m/s) | 3 |
Rated wind speed (m/s) | 9 |
Working wind speed (m/s) | 3-25 |
Survival wind speed (m/s) | 50 |
Generator efficiency | >0.8 |
Wind energy utilizing ratio (Cp) | 0.45 |
Generator type | Permanent Magnet Alternator |
Generator weight (kg) | 25 |
Blade material/quantity | GRP/3 |
Blade diameter (m) | 3.8 |
Mast height (m) | 10 |
Over speed control | Yawing mechanism + Electromagnetic brake |
Shutting down method | Manual + Automatic |
