100% TUV standard mono per watt import sunpower solar panels factory direct 230w

Brand:aa

Product detail:

Features about   100% TUV standard mono per watt import sunpower solar panels factory direct 230w

1. High cell efficiency with quality silicon materials for long term output stability and reliability.
2. High transmittance low iron tempered glass with enhanced stiffness and impact resistance

3. Unique frame design with high mechanical strength for easy Installation.
4 Advanced encapsulation material with multiplayer sheet lamination to provide efficient protection from the severest environmental conditions
6. Outstanding electrical performance under high temperature and low irradiance conditons

Solar panel applications  of  100% TUV standard mono per watt import sunpower solar panels factory direct 230w

1. Any large or small on-grid or off-grid solar power stations.

2. Commercial and industrial building roof-top systems

3. Residential roof-top systems

4. Any commercial or industrial ground mount systems

5. Other industrial or commercial applications

Specification for 100% TUV standard mono per watt import sunpower solar panels factory direct 230w

ELECTRICAL CHARACTERISTICS
Model Number		ZMSOL-230P	ZMSOL-235P	ZMSOL-240P	ZMSOL-245P	ZMSOL-250P
Maximum Power as per STC	Pmax(W)	230	235	240	245	250
Power Tolerance	%	± 3%
Maximum Power Voltage	Vm(V)	30.48	30.6	30.66	30.35	30.46
Maximum Power Current	Im(A)	7.6	7.68	7.83	8.08	8.21
Open Circuit Voltage	Voc(V)	36.6	36.72	36.84	36.36	36.5
Short Circuit Current	Isc(A)	8.17	8.23	8.32	8.79	8.93
Maximum System Voltage	VDC	1000
Cell Efficiency	%	15.8	16.1	16.4	16.8	17.1
Module Efficiency	%	14.1	14.4	14.7	15.0	15.3
Cells per Module	Pcs	60
Cell Type		Polycrystalline silicon
Cell Size	mm	156 x 156
Bypass Diodes	Pcs	12Amp, 6 pcs
Max. Series Fuse Rating	A	15A
Temperature coefficient of Isc	% /	0.05
Temperature coefficient of Voc	% /	-0.35
Temperature coefficient of power	% /	-0.47
NOCT- Nominal operating cell temperature		47 ± 2 degree
Operating Temperature		-40 to +85 degree
MECHANICAL CHARACTERISTICS
Dimensions	mm	1650 x 990 x 50
Weight	Kg	19.8
Type of Junction Box		TUV certified, IP65
Cable Type, Diameter		TUV certified, 4mm 2, 90 cm in length
Connector		compatible to Type 4 (MC4)
Tempered Glass		3.2 mm, high transmission, low iron
