Brand:aa
Product detail:
Hot Selling!!! P16 Advertising LED Display Surprising Price!!!
Specification Parameter
Description | Technical parameter | |
Unit module | Module size | 256*128mm |
Pixel pitch | 16mm | |
Pixel density | 3906dots/m2 | |
Pixel configuration | 2R1G1B | |
Led specification | 546 | |
Pixel resolution | W:16dots*H:8dots | |
Cabinet | Dimension | 1024mm*1024mm*150mm |
Quantities of module | 32pcs | |
Power supply | 4pcs | |
Thermal discharge | Fan*2pcs | |
Total weight | 53kg | |
Best viewing angle | 16-300m | |
Temperature | Storage: -35°C~+85°C | |
Working: -35°C~+85°C | ||
Thickness | 15cm can adjustable | |
Remarks: cabinet size can changed, upon project need. | ||
Power | Working voltage | AC220V/110V±10% |
Average power consumption | 500W | |
Max. Power consumption | ≤800W/sqm | |
Current | ≤20mA(single LED) | |
Control system | CPU | Pentium4 or above |
Operating system | WIN98/2000/NT/XP | |
Control method | Synchronization | |
Main technical parameter | Driving device | static scanning |
Drive type | Constant Current driver IC | |
Refresh frequency | ≥400Hz | |
Grey scale/colors | 256 levels of each color(R/G/B)/16.7M color | |
Brightness of white balance | More than 8500cd/sqm | |
Brightness adjustment | 256 levels of each color(R/G/B)by software | |
Operating ambient humidity | 10%--95% | |
Video signal | PAL/NTSC | |
Control system | DVI display card+full color controller card | |
MTBF | ≥10,000hours | |
Life span | ≥100,000hours | |
Flatness | Tolerance of interpixel ≤0.3mm | |
Tolerance of modules clearance≤0.6mm | ||
Power switch | Automatic switch | |
Display mode | 1024*768 | |
Communication distance | Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m. Multi-mode Optic fiber transmission distance 500m;Single-mode optic fiber transmission distance 10KM | |
Software | LED media player | |
Product advantages:
1) Price Advantage: we have the best competitive price at the market, also have the same even better quality.
2) Quality advantage: From material to finished product, from design to produce, we control all steps
3) Service advantage: Better service at same situation, better cooperation at same service
Trade Terms:
1).Payment: T/T ,ususally 40% prepayment before production, 60% balance to be paid before delivering,it also change according to total quantity
2).Production lead time less 20 sqm: 8-15days, more than 50 sqm:30days
3).Sample can be deliveried within 3days
4).Shipping port: Shenzhen, Mainland China
5).Discounts are offered based on order quantities
6).MOQ:1 sqm/1pcs
Our service:
1).Your inquiry related to our products or prices will be replied in 24hrs.
2).Well-trained and experienced staffs to answer all your enquires in fluent English .
3).OEM&ODM, any your customized screen we can help you to design and put into product.
4).Distributer ship are offered for your unique design and some our current models .
5).Protection of your sales area, ideas of design and all your private information
Technological process
Module picture
The benefits that we can bring you are:
1, Strong quality is one of our products' highlights.
2, Low pover consumption
3. Two-year quality warranty with long life maintenance.
4. Technology with responsibility.
5. Choice of different LED chip available with favorable price.
6, OEM service provided.
For enquiry please contact:
Ms.Ivy Zheng
Oversea Sales Dept.
Skype: qq.ivy123
Website: www.szyaode.com
Shenzhen YaoDe Photoelectric Co., Ltd.
Add: 4th Floor,2 Building,Huiye Technology Park, Tangtou, Shiyan Town, Bao'an District, Shenzhen City, Guangdong Province, China
product effect
Products have got the certification of CE,ROHS,FCC&IP65.
Structure
Packing
wooden case
flight case
Factory
