Brand:aa
Product detail:
HASL PCB board HASL PCB :
1,Pcba 100% test
2,Competitive price,fast delivery
3,UL,SGS,Rohs
Hongchuang can offer one-stop service from schematic design, board layout, component selection, firmware design, and mechanical design to PCBA and chip cloning
Item | Manufacture Capability | |
Material | FR-4 / Hi Tg FR-4 / Lead free Materials (RoHS Compliant) /CEM-3, Aluminium, Metal based | |
Layer No. | 1-16 | |
Finished Board thickness | 0.2 mm-3.8mm’(8 mil-150 mil) | |
| ||
Board Thickness Tolerance | ±10% | |
Cooper thickness | 0.5 OZ-11OZ (18 um-385 um) | |
Copper Plating Hole | 18-40 um | |
Impedance Control | ±10% | |
Warp&Twist | 0.70% | |
Peelable | 0.012"(0.3mm)-0.02’(0.5mm) | |
Images | ||
Min Trace Width (a) | 0.1mm (4 mil) |
|
Min Space Width (b) | 0.1mm (4 mil) | |
Min Annular Ring | 0.1mm (4 mil) |
|
SMD Pitch (a) | 0.2 mm(8 mil) |
|
BGA Pitch (b) | 0.2 mm (8 mil) | |
|
| |
Solder Mask | ||
Min Solder Mask Dam (a) | 0.0635 mm (2.5mil) |
|
Soldermask Clearance (b) | 0.1mm (4 mil) | |
Min SMT Pad spacing (c) | 0.1mm (4 mil) | |
Solder Mask Thickness | 0.0007"(0.018mm) | |
Holes | ||
Min Hole size (CNC) | 0.2 mm (8 mil) | |
Min Punch Hole Size | 0.9 mm (35 mil) | |
Hole Size Tol (+/-) | PTH:±0.075mm;NPTH: ±0.05mm | |
Hole Position Tol | ±0.075mm | |
Plating | ||
HASL | 2.5um | |
Lead free HASL | 2.5um | |
Immersion Gold | Nickel 3-7um Au:1-5u'' | |
OSP | 0.2-0.5um | |
Outline | ||
Panel Outline Tol (+/-) | CNC: ±0.125mm, Punching: ±0.15mm | |
Beveling | 30°45° | |
Gold Finger angle | 15° 30° 45° 60° | |
Certificate | ROHS, ISO9001:2008, SGS, UL certificate | |
Short Lead Time and Urgent Service:
Layers | Sample | Mass order | Urgent |
1-2L | 3-5 days | 5-7days | 12-24hours |
4- 8L | 5-7days | 7-10days | 48-96hours |
10-18L | 7-10 days | 10-12days | 120hours |
20-28L | 15-20 days | ||
