Brand:aa
Product detail:
2500W dc ac pure sine wave inverter off grid inverter single phase inverter
The product is 2500w pure sine wave power inverter, which converts 12V/24V DC to 100V/110V/120V/220V/230V/240V (50Hz/60Hz) AC, based on high performance and intelligent design. It has the features of high reliability, high efficiency, low weight, small volume, full protection functions, easy installation and operation. The inverter can be applied in many fields such as car,home and solar photovoltaic power system.
l Whole excellent PWM control technology and electromagnetic compatibility design
2 Intelligent design
3 Wide DC input voltage range
4 pure sine wave output with high efficiency and stability
6 LED indicators for normal output & failure state
7 Short-circuit, overload, overvoltage and over-temperature protections; and low battery voltage alarm and protection
8 Fitted for many kinds of AC loads such as household appliances, electric tools, industrial devices and electronic video and audio
9 Wide working temperature range (industrial level)
Specifications
Model | HYP2500-121 | HYP2500-122 | HYP2500-241 | HYP2500-242 |
Output voltage | 110V | 230V | 110V | 230V |
Input voltage | 12V | 12V | 24V | 24V |
High Volt Cut off | 15-16V | 30-32V | ||
Low Volt Alarm | 10.5±0.5V | 21±1V | ||
Low Volt Cut Off | 10±0.5V | 20±1V | ||
Rated power | 2500W | 2500W | ||
Surge power | 5000W | 5000W | ||
Output frequency | 50±2Hz OR 60H±2Hz | |||
USB port | 5V 500mA | |||
Output waveform | Pure Sine Wave | |||
No load current | <1.0A | |||
Efficiency | >80% | |||
THD | <3% | |||
Max. outer temperature | <65°C | |||
Packing | Gift box | |||
Brand | HOOVS or OEM | |||
Warranty | 24 months | |||
Protection | |
LED Display | Yes |
Buzzer Alarm | Yes |
Over-load Protection | Yes |
Over-voltage Protection | Yes |
Low-voltage Protection | Yes |
Over heat pretection | Yes |
Short-circuit protion | Yes |
Product category |
Modified Sine Wave Power inverters: 100W~4000W |
Pure Sine Wave Power Inverter: 100W~4000W |
Power inverter with chargers(UPS): 200W~4000W(UPS) |
Lead acid battery chargers:12V/24V 0.5~30Amp |
Solar Inverter(Inverter + solar charge controller built in ): 200W~4000W |
| Inverter + Solar controller + Battery charger (3 in 1): 200W~4000W |
| Solar charge controller: 12V/24V 5-30A |
| DC-DC Converter: 24V-12V/ 1-20A, 12V-6V/1-20A, 48V-24V,1-20A...... |
REPLACEABLE SOCKET TYPE
