(0.5T~50T) Best Quality CE approved Ice Block Machine

Brand:aa

Product detail:

(0.5T~50T) Best Quality CE approved Ice Block Machine



1.ABOUT OUR FACTORY

Our main products:tube ice machine,block ice machine,fresh

water flake ice machine,sea water flake ice machine,water chiller,cube ice machine and related equipment

to the ice machine.

2.ABOUT OUR PRODUCT

*Power supply:3PH-200V/220V/380V/415V-50HZ/60HZ

*Refrigerant  R22/R407C/R134a

*Set temperature range: From -30 to +35°C

*Cooling capacity: 0.6HP-720HP (0.5tons-700tons)





1)FEATURES OF ICE BLOCK



Ice weight:10 kg,15kg,20kg,25kgs.50kg,75kg,100kg,125kg

Color of ice,white or transparent as you need.

Transparent ice can be made by ruling out the dissolved air in water in the ice forming process.



2)ADVANTAGE OF ICE BLOCK



Block ice produced by brine block ice machine is close-grained,hard,difficult to melt,and easy to store and transport.Decades of production practice has proved that in the ice industry brine ice is diffcult to replace by other ice-making process.



3)THE PROCESS OF MAKING ICE BLOCK



ICE BLOCK IN THE BRINE TANK







ICE CANS BEING LIFTED BY CRANE







ICE DUMP







ICE OUT







SPIRAL EVAPORATOR IN THE BRINE TANK









3.TECHNICAL PARAMETER FOR ICE BLOCK MACHINE(8 TONS FOR EXAMPLE)



Model	-	SAB80
Capacity	Ton/d	8
Refrigeration capacity	kW	49.5
Input power	kW	29.75
Rated current	A	51.4
Power supply	-	380V-3P-50Hz
Ambient temperature	°C	35
Water inlet temperature	°C	20
Ice temperature	°C	-8
Compressor power	kW	27.7
Refrigerant	-	R404A/R22
Cooling way	-	Water cooling/Air cooling
condenser Capacity	kW	78
condenser water flow	M3/H	13.416
Cooling tower power	kW	0.55
Cooling pump power	kW	1.5
Power of cutter	kW	0.75
Chilling pump power	kW	1.5
All water consumption	M3/H	0.467
Size of ice maker	L×W×H mm	9560×2200×2200
Size of evaporator	L×W×H mm	Included in the unit
Operating weight	Kg	6250



Product Model Catelog	Capacity:Tons/daily
Small capacity block ice machine	0~3
Medium capacity block ice machine	3~10
Large capacity block ice machine	>10



Model	Capacity:ton/daily	Input power:kw	Refrigerant
SAB10	1	4.62	R404A/R22
SAB20	2	6.26	R404A/R22
SAB30	3	8.62	R404A/R22
SAB50	5	16.28	R404A/R22
SAB80	8	29.75	R404A/R22
SAB100	10	38.15	R404A/R22
SAB120	12	42.35	R404A/R22
SAB150	15	56.25	R404A/R22
SAB200	20	66.55	R404A/R22
SAB250	25	87.5	R404A/R22
SAB300	30	102.6	R404A/R22



4.PACKING DETAILS

  Brine tank in wooden case as below.
