Brand:aa
Product detail:
Solar Inverter With Built-in Charge Controller 3kw 5kw 10kw(ship the free parts for service)
There are some problem for Alibaba inquiry system,if you want to get more information,pls contact us directly!
Mobile:86-15302966051 Skype:tanfonlucy email:lucy at tanfon.com
1.Combine with solar power controller and inverter hybrid function.
2.Completely controlled by CPU.
3.Inverter use copper transformer, pure sine wave output.
4..Two LCD displays, clearly to know the status.
5..Perfect protection. Protect against anti-charge at night, battery over charger/over discharge, output short-circuit, against overload, against over-voltage, over-current protection ,etc.
*******We sincerely hope that can cooperate with you in the future********
Model | SC2000 | SC3000 | SC5000 | |||
Rated power(W) | 2000W | 3000W | 5000W | |||
Rated DC voltage(V) | 48V or 96V | |||||
Line input | Input voltage(V) | 165-275V | ||||
Charge current(A) | 30-80A | |||||
Inverter output | Output voltage(V) | 220VAC±5% | ||||
Output frequency | 50Hz/60Hz±1% | |||||
Wave form | Pure Sine Wave, THD<4%(Full Load) | |||||
Solar input | Maximum voltage((V) | 84V or 168V | ||||
Rated power(Wp) | 2000 | 3000 | 5000 | |||
Charge current(A) | 40 | 40/60 | 60/80A | |||
DC Loads | Rated voltage(V) | 48V or 96V | ||||
Rated current(A) | 20-30A | |||||
Over discharge protective voltage of battery(V) | 43.2V or 86.4V | |||||
Over discharge recover voltage of battery(V) | 50V or 100V | |||||
Others | Voltage drop between solar module and battery(V) | ≤0.5V | ||||
Voltage drop between loads and battery(V) | ≤0.25V | |||||
Start speed of cooling fan | Have | |||||
Environment Humidity | 0-90% Maximum,non-condensable | |||||
Protective Functions | Protection against anti-charge at night;Battery over charge/ over discharge protection; Joint-reversed of solar modules | |||||
Control method | MPPT | |||||
Size :D*W*H(mm) | 450*230*480 | 450*230*570 | ||||
N.W&GW(kg) | 32/38 | 40/49 | 49/58 | |||
