60% Off! Cummins 68KW Soundproof Diesel Generator
Product Details (Silent Style):
Main Technical Data Reference (Soundproof Style):
GENERATOR SET | |
Genset Model | ZDE-68ST3 |
Prime Power (KVA/KW) | 85/68 |
Standby Power (KVA/KW) | 92.5/74 |
Frequency & Voltage | 400/230V, 50HZ |
Number of Phase | 3 |
Genset Type | Silent/Soundproof |
Reference Dimension & Weight (W*H, mm)/KGS | 2650*1060*1450,1700KGS |
DIESEL ENGINE | |
Engine Brand & Model | Cummins 6BTA5.9-G1 |
Rated Output | 58KW |
Rated Speed | 1500RPM |
Engine Type | Four stork, in-line water cooled |
Number of Cylinder | 6 |
Bore * Stroke | 105*125mm |
Aspiration Method | Trubocharged |
Governor | Mechanical |
Starting Method | Electric starting |
Cooling Method | Forced water cooled |
Lubrication Method | Pressure & splash lubricating |
Fuel Consumption | 21.5 L/H |
ALTERNATOR | |
Alternator Brand & Model | Stamford/Leroy Somer |
Type | Brushless & self-excited |
Number of Phase | 3 |
Volatage | 400/230V |
Frequency | 50HZ |
Power Factor | 0.8 |
Insulation Grade | H |
Protection Grade | IP22/23 |
Altitude | ≤1000m |
Product Details (Open Style):
Main Technical Data Reference (Open Style):
GENERATOR SET | |
Genset Model | ZDE-68OT3 |
Prime Power (KVA/KW) | 85/68 |
Standby Power (KVA/KW) | 92.5/74 |
Frequency & Voltage | 400/230V, 50HZ |
Number of Phase | 3 |
Genset Type | Open |
Reference Dimension & Weight (W*H, mm)/KGS | 2160*800*1460,1270KGS |
DIESEL ENGINE | |
Engine Brand & Model | Cummins 6BTA5.9-G1 |
Rated Output | 68KW |
Rated Speed | 1500RPM |
Engine Type | Four stork, in-line water cooled |
Number of Cylinder | 6 |
Bore * Stroke | 105*125mm |
Aspiration Method | Trubocharged |
Governor | Mechanical |
Starting Method | Electric starting |
Cooling Method | Forced water cooled |
Lubrication Method | Pressure & splash lubricating |
Fuel Consumption | 21.5 L/H |
ALTERNATOR | |
Alternator Brand & Model | Stamford/Leroy Somer |
Type | Brushless & self-excited |
Number of Phase | 3 |
Volatage | 400/230V |
Frequency | 50HZ |
Power Factor | 0.8 |
Insulation Grade | H |
Protection Grade | IP22/23 |
Altitude | ≤1000m |
