Product detail:
The specification of HT brand diesel generator
Genset model:HT-16GF HT-1200GF
Type:open/sound proof/weather proof/trailer type
Generatort output power range: 16kw-1200kw
Rated voltage:220/380V,230/400V,240/415V,120/240V as required
Frequency: 50/60HZ
Power factor:0.8
Rated speed:1500/1800rpm
Output type: AC three phase/single phase
Alternator: brushless
Frequency:<3%
Frequency at stable state:<0.5%
Frequency deviation at instantaneous state:≤+10%
Frequency return time:≤3s
Voltage deviation at stable state:≤±1%
Voltage deviation at instantaneous state:≤+20%
Voltage return time:≤4s
Voltage modulation:≤0.3%
Cummins brand diesel generator (Our Cummins diesel generator power ranges from 16kw to 1200kw ,the picture is just for your reference ):
Cummins brand diesel generator :
Model | Dongfeng Cummins series: 4B3.9-G1; 4BT3.9-G1; 4BTA3.9-G1; 6BT-5.9G1; 6BTA-3.9G2; 6BTAA5.9-G2; 6CTA8.3-G2; 6CTAA8.9-G2 Chongqing Cummins series: MTAA-G3; NTA855-G2; KTA19-G3;KTAA19-G3; KTA38-G2; KTA38-G5; KTA50-G3....... |
Cooling Method | water-cooled |
Rotating speed | 1500/1800rpm |
Governor system | electrical or mechanical governor |
Aspiration mode | natural aspirated or turbocharged |
Starting method | 12/24V DC electric starting |
Stroke | 4 stroke |
Ricardo Brand diesel generator (our Ricardo brand diesel generator range from 8kw to 150kw , the picture only for your reference )
| Weifang Ricardo brand diesel generator : | |
| Model | 295D, 2100D, 495D/ZD, K4100D/ZD, R4105D/ZD, R6105D/ZD.R6105AZLD, R6105IZLD , 6113ZLD ... |
| Cooled type | Water cooled |
| Rated speed | 1500/1800rmp |
| Starting method | 12/24V DC electric Starting |
We also have the Lovol-Perkins brand , Deutz brand , Steyr brand for the diesel generator
The brushless alternator for Weifang Diesel Generator :
Compliance with GB755,BS5000,VDE0530,NEMA MG1-22,IEC-34,CSA C22-100and AS1359 standards.
Brand | Stamford,marathon, leroy somer.ect |
Regulator | AVR automatic voltage regulating |
Excite type | pret or shunt |
Connecting type | 3PH star, 3PH-DELTA |
Steady frequency change | 0-5% |
No load voltage | ≥95%-105 |
Steady voltage | ≤±1 |
Insulation degree | H degree |
Exclosure degree | IP23 |
Standard configuration of Weifang Diesel Generator :
1) Starting system: DC alternator is used to start engine
2) Short circuit protection: MCCB air switch
3) Cooling system: combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40°C
4) Filter system: oil, fuel and air filter
5) Accessories: exhaust elbow, bellow, muffler
Our product's Features of
| Features: | 1. Noise level is less than 78Db ( within 1 meter ) | |
| 2. using 2-4mm steel plate as shell | ||
| 3. New flam retardant soud-absorbing material | ||
| 4. Outside steal owns preferable corrosion protection capability | ||
| 5. Double-door design for easy maintenance | ||
| 6. Exhaust pipe insulation | ||
| 7.Security door locks | ||
| 8. Advanced desigh for air intake and outlet | ||
| 9. Large impedance composite muffler | ||
| 10. Convenient fuel inlet | ||
| 11. Convenient engine lubricating oil discharge opening | ||
| 12. Hoist & Fork truck set for easy moving | ||
| 13. Safe electric cable output connection | ||
After sale-service:
18 moths warranty on spare parts free provide & technical support in machine life.
To be the best partner of electric power equipments.
Please contact us for more details.
