SMS/GPRS GPS Car Tracking TKV103B

Brand:aa

Product detail:

Easy Installation GPS Car Tracking with engine cut and backup battery function





Cut oil, ACC ignition detection,  vibration alarm, over speed alarm, backup battery, power disconnect alarm



1. General



LDW-TKV103B is remote vehicle positioning device comprising GPS and GSM/GPRS modules. Based upon the GPS satellite, it shall offer you precise positioning information on dynamic conditions. The remote vehicle positioning device shall send longitudinal and latitudinal coordinates to the authorized cell phone, which can be utilized by you to position and manage your own vehicles.



2. Appearance





3. Application Fields

• Vehicle monitoring
• Car positioning
• Logistic monitoring
• Any other fantasy fields



4. Product Features



•  Individual or fleet GPS polling
•  Worldwide use
• Supports GSM frequencies 850/900/1800/1900MHz
• High-sensitivity, latest technology and the most advanced GPS chip
•  Can accurately position even if with weak signal
• Can work effectively in limited space such as the remote and narrow places;
• compact size, easy for hiding
•  Low energy consumption
•  Fast signal capturing
• supports two modes: text message polling and GPRS trace tracking
•  Alarm function
• SOS button
• cut oil
• over speed alarm
• acc ignition detection
• vibration alarm



5.  Product Specifications



(1). Technical Specifications



GSM FREQUENCY	850/900/1800/1900MHz
GPS CHIPS	SIRF IV
GPRS	Class 12, TCP/IP build in GSM MODULE
GPS SENSITIVITY	-159dBm
GPS ACCURACY	10m (2D RM)
GSM ACCURACY	50-200m
SPEED ACCURACY	0.1m/s
COLD STATUS	-38s
WARM STATUS	-32s
HOT STATUS	-2s
MAXIMUM ALTITUDE	18000m
HIGHEST SPEED	515m/s
ACCELERATION OF GRAVITY	<4g
SIZE	72.00(L) x 38.0(W) x17.0(H) mm
WEIGHT	45g





(2). Others



WORKING TEMPERATURE	-20--+70°C
HUMIDITY	20%---80%RH
VOLTAGE	7—30v DC
CURRENT	~60mA(12v DC)     ~35mA(24v DC)
STANDARD AVERAGE CURRENT	<80MA
LED	LED indicate GPS,GSM working status or other condition







 6. Package



1. Gift box Measurement: 145*93*66mm



    Total weight with gift box: 0.27kg



2.Quantity/carton: 45 units



    Carton dimensions: 46*35.5*30cm



    N.W./carton: 13.2kg

















7. Installation advice









8. Tracking System







9. Certificate



1. CE





2. ROHS
