X ray Luggage scanner apply to hotel, airport,subway station,railway station security

Brand:aa

Product detail:







Technical parameters of K10080







Product description



Basic parameters:



Tunnel size:  1000(W)*800(H) mm
Speed of the belt:  0.22m/s
Rated load of the belt:  200Kg
resolving power:  Diameter is 0.101mm of the metal line
Space resolution:  level: OD1.3mm   vertical: OD1.0mm
Through resolution:  OD0.511mm
Penetration ability:   steel plate’s thick is 34mm
Film safety:  ISO1600 film is safe
Leak dose :   <0.1µGy/h







X-ray generator:



Beam direction:   light from top
Tube current:  0.4~1.2mA (adjustable)
Tube voltage:  100--160 KV (adjustable)
spread Angle of the ray beam :  80°
Cooling/work cycle :   Sealed oil cooling/100%




Image processing system:



X ray sensor :  L photoelectric diode array detector(multi energy), 12bit depth
Display :   High resolution 17 "LCD display
Color image display :   According to the material is qualitative, 24 bits true color display
Edge enhancement :   The object contour edge clearer
Super image enhancement :   Image detail more clearly
High penetration show :  Improve the image of the bright contrast, make easy penetration area more clearly
Low penetration show :   Improve the image of the dark contrast, make difficult to penetrate area more clearly





Magnifier:   Local amplification function, real-time dynamic amplification
Brightening/darken:   Increase the brightness of the image/Reduce the brightness of the image
Image back to pull:   Before the show and image, and the image can be any image processing
Image restoration:   Image display restore the original state
Image storage:  Real-time save any image, and can be arbitrary image processing, continuous work save


Multi energy color:   Organic display for orange, Inorganic display for blue, Mixture display for the green
High energy/Low energy:  Two kinds of energy switch display
Drug and explosive auxiliary detection:  Some of the more typical auxiliary detection of drugs and explosives and other dangerous articles







Use environment:



System temperature/humidity :    0°C~45°C/20%~95% (No condensation)
Storage temperature/humidity :  -20°C~60°C/20%~95% (No condensation)
System voltage :   220VAC(±10%)  50±3HZ
Power loss :   1.5KW(max)

Noise level :   <58dB





Used for:



• Airports
• Banks
• Commercial buildings
• Courthouses
• Embassies
• Government buildings
• Military installations
• Prisons
• Ships
• Security checkpoints
• Post office
• ...
