Shenzhen airport x-ray scanner K5030A

Basic parameters:

Size of tunnel: 500(W)*300(H)mm
Conveyor speed:   0.22m/s(adjustable)
Conveyor max load:  150Kg
Wire resolution :   0.101mm metal line
Steel penetration:   10mm armor plate
Film safety:   for ISO1600
Maximum leakage radiation:   <0.05µGy/h

Ray direction :   orientation vertically upward
Tube current :   0.4~0.5mA(adjustable)
Tube voltage :   80KV(adjustable)
Angle of X-ray:   80°
Cooling/working periods :   Sealed oil bath /100%

Image processing system:

X ray sensor :

L type photoelectric diode array detector(single energy), 12bit depth

Monitor :

High resolution 17 "LCD display

Color image display :

24 bits nature color display

Edge enhancement :

The object contour edge more distinct

Super image enhancement :

Image detail more clearly

High penetration display :

Improve the image contrast of the bright area, make easy penetration area more clearly

Low penetration display :

Improve the image contrast of the dark area, make the difficult penetrated area more clearly

Magnifier:

function of partial enlargement

Brightening/ darkening:

Increase the brightness of the image/ Reduce the brightness of the image

Image recurrence:

display previous twenty images and process any one of them

Image restoration:

restore image to initial status

Image storage:

save any image real-time, and process any one of them in operation status.

Supplier Product Code

K5030A

Operating environment:

Operating temperature/humidity :   0°C~45°C/20%~95% (non-condensing)
Storage temperature/humidity :   -20°C~60°C/20%~95% (non-condensing)
Operating voltage :   220VAC(±10%) 50±3HZ
Power wastage:   1.0KW(max)
Noise:   <60DB
