Portable x ray machine price K5030A

                                                                    Basic parameters:

                                Size of tunnel: 500(W)*300(H)mm
                                Conveyor speed:   0.22m/s(adjustable)
                                Conveyor max load:  150Kg
                                Wire resolution :   0.101mm metal line
                                Steel penetration:   10mm armor plate
                                Film safety:   for ISO1600
                                Maximum leakage radiation:   <0.05µGy/h

                                 Ray direction :   orientation vertically upward
                                 Tube current :   0.4~0.5mA(adjustable)
                                 Tube voltage :   80KV(adjustable)
                                 Angle of X-ray:   80°
                                 Cooling/working periods :   Sealed oil bath /100%

                                                                    Image processing system:

                                X ray sensor :

                                L type photoelectric diode array detector(single energy), 12bit depth

                                Monitor :

                                High resolution 17 "LCD display

                                Color image display :

                                24 bits nature color display

                                Edge enhancement :

                                The object contour edge more distinct

                                Super image enhancement :

                                Image detail more clearly

                                High penetration display :

                                Improve the image contrast of the bright area, make easy penetration area more clearly

                                Low penetration display :

                                Improve the image contrast of the dark area, make the difficult penetrated area more clearly

                                Magnifier:

                                function of partial enlargement

                                Brightening/ darkening:

                                Increase the brightness of the image/ Reduce the brightness of the image

                                Image recurrence:

                                display previous twenty images and process any one of them

                                Image restoration:

                                restore image to initial status

                                Image storage:

                                save any image real-time, and process any one of them in operation status.

Supplier Product Code

K5030A

                                                                 Operating environment:

          Operating temperature/humidity :   0°C~45°C/20%~95% (non-condensing)
                        Storage temperature/humidity :   -20°C~60°C/20%~95% (non-condensing)
                                 Operating voltage :   220VAC(±10%) 50±3HZ
                                       Power wastage:   1.0KW(max)
                                                          Noise:   <60DB
