Product detail:
Heavy duty pallet racks
structured with pallets and beams are most widely used.
This kind of steel pallet racking is widely used together with forklifts , steel storage containers, steel pallets and storage boxes.
Features:
1. pallet rack is designed to store pallet cargo. It enables you to make full use of the storage space. With a wide range of optional solutions and components available, we can design special pallet racking according to your requirements.
2. pallet racking can be coupled with different specifications of pallets and containers.
3. It can coordinate with all the handling equipment and operational equipment,
4. pallet racking is manufactured in accordance with international quality standard ISO9001:2000, as well as international design standard SEMA, FEM, and AS4084.
Each level can be adjustable at 75mm per pitch and the maxmum loading is 25000kg with the maxmum length of 12 meters.
Each level loading duty is from 200kgs to 8000kgs, depending on the beam length.
Required information from customers for quick quote:
1, the AUTOCAD drawing or draft drawing of warehouse or racking.
2, the size of the warehous, length, height, and width.
3, how many layers of the racking?
4, your pallet size.
5, max weight of pallet with cargo on.
6, special color requirement.
Standard Size:
S/N | Standard Size(W*D*H) | Loading Weight | Standard Layer | Material |
1 | 2300*900*3000 | 1000-4000kg/level | 2+1(ground) | steel |
2300*900*4000 | 3+1(ground) | |||
2300*1000*3000 | 2+1(ground) | |||
2300*1000*4000 | 3+1(ground) | |||
2 | 2500*900*3500 | 2+1(ground) | ||
2500*900*4000 | 3+1(ground) | |||
2500*1000*3500 | 2+1(ground) | |||
2500*1000*4000 | 3+1(ground) | |||
3 | 2700*900*3500 | 2+1(ground) | ||
2700*900*4000 | 3+1(ground) | |||
2700*900*5000 | 3+1(ground) | |||
2700*900*6000 | 4+1(ground) | |||
2700*1000*3500 | 2+1(ground) | |||
2700*1000*4000 | 3+1(ground) | |||
2700*1000*5000 | 3+1(ground) | |||
2700-5000*1000*6000-12000 | (4,5,6...)+1(ground) | |||
| Remark:This size is our standard only. Different size with various loading weight and levels are acceptable. | ||||
