Sound&light security walk through gate metal detector door

Basic parameters:

Gross Weight: 80kg

Outer frame: 2200mm (h)*820mm (w)*500(d)

Inner frame: 2000mm (h)*700mm (w)*500mm (d)

Characteristic:

1. Detection area:

According to the basic structure of the human body, the detector divide into multiple overlapping region, it use mesh detecting ways and single frequency excitation technology, eliminate the weak detection of the region and the blind spot area, it is higher sensitivity and stable.

Alarm mode:

Sound-optical alarm, detect accurately the location of metal objects through high alarm LED lights in the column 6 Pinpoint zones to precisely identify multiple target locations from head to toe.

2. Sensitivity adjustable from Level 0 to 99(100 levels)

(1).High: Can detect a pin

(2).Low: Detect big metal articles such as: knife ,gun and copper, aluminums, zinc(more than 150g),ignoring metal in belt button, shoes.

3. Shock proof to avoid false alarm.

4. Sound and light alarm.

5. 2 LED light bars on both door panels: gives alarm corresponding to the height or human body.

6. Mix distance between two Walk-thru: 0.3 meters at low sensitivity, 0.5 meters at high sensitivity.

7. Remote control unit (Optional).

Supplier Product Code

K208
