Mini gps tracking device tk102 with Monitoring and SOS feature

Brand:aa

Product detail:

Mini gps tracking device tk102 with Monitoring and SOS feature



Parameter:







Items	Specifications
Dimension	64 x 46 x 17mm
Weight	50g
Charging Voltage	Mini USB charging interface Car charge:12-24v input 5v output wall charge: 110v-220v input 5v output
Battery	3.7V 860mAh Li-ion battery Standby:48hours
Power Consumption	800mAh standby current
Operating Temp.	-20°C~55°C
Storage Temp.	-40°C to +85°C
Work Time	100hours in sleep mode and 10 hours in normal mode
LED	LED lights to show power, GPS, GSM and other status
Button	2 buttons for SOS and Turn on/off
GSM Frequency	GSM  850/900/1800/1900Mhz or900/1800/1900Mhz
GPS Sensitivity	-159dB
Positioning Accuracy	5m-50m







 Function:











Feature:















• Ø  GPS and Location Based Service







Location Based service also named A-GPS, when tracker in underground or tunnel ,can get location by AGPS.







• Ø  Real time tracking







Real time tracking it by cell phone and platform . Also can support get location every 5 seconds, and the GPS accuracy is 5m .







• Ø  Check the history of route







Can check and replay within one year history of route of device ,by web monitor center







• Ø  Monitoring and communication







    Can hear the voice around the tracker by cell phone . Also support communication with the tracker by cell phone (OEM)







• Ø  SOS button







SOS button ,when user have emergency , press the SOS button ,the tracker will send “help me “ SMS to all authorized phone number and monitoring web platform.







• Ø  Mileage calculate







Check the mileage data by mobile and platform anytime and anywhere.







• Ø  Google map on mobile







Check the location with google map on mobile.







• Ø  Geofence and movement alert







 Set up a geo-fence for the unit to restrict its movements within a district ,unit will send a message to the authorized numberwhen it breaches the district..







• Ø  Overspeed alert







set up the speed as your requirement, and will get the alert when overspeed.























Pictures for TK102 mini gps tracker:





























 Size parameter:





















 Details introduction:





















Correct way to insert SIM card :





















New battery charger:       (UK/USA/Europe/Australia)





















Application and convenient by using cellphone:(use for pet/person/elder/car)





























How does it work:







 1. You will need to insert a working sim card into the GPS unit. Whenever you send a text message to the unit it will respond with coordinates of where it is located.















    You can use these coordinates on any mapping software (for example google earth) which will show where exactly your object is.















2. You  can send command to the gps, change the text masage to google map link. so you can check the link directly.















3. You can request the unit to constantly send you coordinates at specific intervals (minimum 30sec), or send you x number of positions every i.e. 30 sec.















How to tracking:













Free tracking platform:















Platform web:www.gpsagps.com  Demo account:348848/123456















Best and easiest way:  Just a call or a sms. you will get a location SMS with google link  and Realtime tracking on platform web:





























 what should do before tracking on line:







 1-Must set APN:







 --APN stands for Access Point Name. For example , China mobile APN:“CMNET”, user name:fido , password:fido.







 --So send SMS“123456apn  cmnet  fido  fido”to the unit















 Notice: APN without account and password is best















Package list:













welcome to send inquiries to me,if you want more details or price,thanks!!
