Brand:aa
Product detail:
supply nature rubber fire hose with the following features :
1)high pressure resistance, high tenacity
2)wear-resisting, aging quality resistance
3)light weight and high flexible
good flexibility, smooth smearing layer
4)non-permeable
5) applications: fire fighting engines, high building fire fighting project, mining and marine use, agrcultural irrigation
Technical Parameters
Model | Diameter | Working Pressure (MPa/Bar/Psi) | Test Pressure (MPa/Bar/Psi) | Burst Pressure (MPa/Bar/Psi) |
Length | |
Inner Dia (inch) | Inner Dia (mm) | |||||
C 8
| 1.5 | 40 |
0.8 / 8/120 |
1.6/16//240 |
2.4/24/360 |
10m-50m |
2 | 50 | |||||
2.5 | 65 | |||||
3.2 | 80 | |||||
4 | 100 | |||||
C 10
| 1.5 | 40 |
1 / 10/150 |
2/20//300 |
3/30/450 |
10m-50m |
2 | 50 | |||||
2.5 | 65 | |||||
3.2 | 80 | |||||
4 | 100 | |||||
C 13
| 1 | 25 |
1.3/ 13/190 |
2.6/26//380 |
3.9/39/570 |
10m-50m |
1.5 | 40 | |||||
2 | 50 | |||||
2.5 | 65 | |||||
3.2 | 80 | |||||
4 | 100 | |||||
C 16
| 2 | 50 |
1.6 / 16/240 |
3.2/32/480 |
4.8/48/720 |
10m-50m |
2.5 | 65 | |||||
3.2 | 80 | |||||
C 20 | 2 | 50 |
2 /20/300 |
4/40/600 |
6/60/900 |
10m-50m |
2.5 | 65 | |||||
3.2 | 80 | |||||
