150M IR Range7-inch,RS485,video surveillance equipment

Click for original picture
Fob Price: 500.00 USD/
MOQ: 1
Payment Terms: delivery withindays since payment
Location: China
  Mr. Jeven Ye    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:

150M IR Range,26x Optical Zoom,7-inch ,rs485,Sony ptz IR speed dome camera





Model NO.GR-CS70326N
Operation
OSD menuEnglish, Chinese, , Russian, Spanish Optional
Preset position256 Preset Positions
ScanAuto scan and left-right limited scan, speed adjustable
Patrol8 tracks, preset, speed and dwell time changeable
Pattern6 Lines(Pan/Tilt/Zoom, every line can record up to 120 seconds)
Alarm4 alarm inputs , 2 alarm outputs(optional)
Password protectionYES
Temperature display and SettingsYES(Temperature alarm set, Temperature Display)
Authority ManagementYES
Private maskingSONY:24(Linked Private masking)
Samsung:8(Linked Private masking)
Address range0~255 (Setup by dip switcher, firmware )
CommunicationRS485 (+/-)
Baud rate2400/4800/9600/19200
ProtocolPELCO-D, PELCO-P , ULTRACK, VICON, DYNACOLOR
Device titleDisplay on/off
Zoom timesDisplay on/off
Firmware Update interfaceRS485 (+/-)
Mechanical
Pan range0°~ 360° continuously
Pan speed0.1~ 240°/s
Tilt range0°~ 90°, Auto Flip 180°to Continue Monitor
Tilt speed0.1~ 180°/s
Precision±0.10°
Infrared
IR Distance150 Meters
IR ControlAuto/Manual
IR DriverPWM
IR Detect Time2~15s, Sync with the Camera
IR Light Level0~30 Adjustable
IR Sensitivity0~30 Adjustable
Standby LevelOFF/1~30 Adjustable
IR ModeAuto/Far/Near/Far Near/Close
Others
HousingAluminum Alloy, Vandal Proof Housing, Wall Mount, Ceiling Mount
Lighting proof6000V
Ingress protectionIP66
Work temp-40°C~+60°C
Work humidity0%~90%
PowerAC24V/4A
Weight4.8kg
Sizeφ223.98*290.83mm
Integrative Chip
ModelSONY FCBEx-980
Image Device1/4" Sony ExViewHAD
Horizontal Resolution480TVL(Color),570TVL(B/W)
Optical Zoom26x   f=3.5mm-91mm(F1.6-F3.8)
Min. Illumination0.07Lux(color),0.01Lux(B/W),0Lux(IR ON)
OtherAuto Color to B/W,IR filter
