Four beams 150 meters long range detector

Click for original picture

Fob Price：

69.00 USD/

MOQ：

50

Payment Terms：

delivery withindays since payment

Location：

China

Ms. Rainta Lee

Product Detail

Brand:aa

Product detail:

Four beams 150 meters long range detector

--KRH-150

Infrared transceiver optical filter housing
Using offset-fed parabolic reflector of high precision optical lens
Unique displacement to accept high power transmitting device, the remainder arrive to 90%
Full featured diagnostic environment Adaptive fault lock
Two independent step-by-step precision trimming built-in optical sight

Parameters of the Four beams 150 meters long range detector .

Model: KRH-150

Outdoor Aleart Distance:150m	Ralative Humidity:5%~95%RH (No condensation)
Indoor Alert Distance:450m	Size:400230125mm
Beams:4 beams	Tamper output :Contact output NC
Detection Mode:4 beams simultaneously	Contact Rating:AC/DC30V,0.5Amax
Lamp source: Infrared-pulse	Horizontal Fence Detector Adjust: 180°,(±90°)
Sensor speed:35~700msec adjustable	Vertical Fence Detector Adjust:20 °(±10°)
Alert Output:Relay Contact Output NO or Nc	Case Material:PC engineering materials
Contact Rating:AC/DC30V,0.5Amax	Weight:1.80kg/pair
Working Voltage/Current:DC/12~18V/≥105mA	Gross Weight:2.1kg/Pair
