Product Name: LCD wireless/wired GSM household alarm system door alarm
Alarm system Main Feature :
This system is high grade LCD screen GSM phone lines and large type double nets home/commercial security alarm system, combining advanced GSM digital signal processing technology, innovation development of the GSM wireless mobile and traditional telecommunication network combination of intelligent alarm system. It was highly integrated digital voice, short information, learning type wireless remote control to code, home appliance, SMS recognition technology.Alarm and automatic speech or SMS alert and the place, told stable, reliable, safe, and manipulation of the human nature. Functional practical, high performance/price ratio, configuration is complete, easy to operate. Big screen Chinese liquid crystal display alarm orientation. Wireless connection infrared, magnetic door, smoke detectors, gas detector, the emergency button and other accessories. Widely used in the family, factories, schools, shops, convenience stores, financial room, villas, community need to be protective place. The protection of property are not violated.
Alarm system Description:
1. Large LCD English blue back-light display, voice prompt, ease of use.
2. Support dual-network of both PSTN landline and GSM mobile network, provide redundancy for extra stability.
3. Can check status and call records from panel.
4. Allow up to 99 wireless defense zones and 4 wired zones.
5. Each can be defined as one of the 8 zone types including NORMAL, STAY, INTELLIGENT, EMERGENCY, CLOSED, HELP SENIOR, WELCOME and CHIME.
6. Four sets of scheduled arm/disarmed function, each time disarmed you can select the included period of time and different defense zone, eliminating of need of the manual procedure, realizing the beauty of automatic controls.
7. Support configuration via phone ( handset ) or SMS messages to System Setup text messaging costs associated with the alarm panel.
8.6 group voice alarm phone number for alert calling, 3 group phone number for help senior, 6 group for SMS messaging, numbers saved inside EEPROM without lost upon power failure.
9. Different zones can dial a pre-set telephone number.
10. Support ISD automatic voice mailbox for playback message upon alert. Maximum length of voice message is 10 seconds.
11. Telephone (phone) long-distance telephone control for arming, disarming, monitoring, remote announcement.
12.1 Set of normally open signal outputs, relay linkage output, home appliances remote control can be realized.
13. Wireless intelligent study coding, compatible with PT2262 normal encoding and a 1527 encoding, convenient and flexible for adding or reducing accessories. Maximum support 150 remote control and 150 sensors.
14. Unique black box features, you can display most recent 72 disarmed records and 102 recent alarm recording. Accurately shows the alarm time and control code.
15. Built-in Ni-Hi rechargeable battery and automatically switchable upon power failure, and notification will be sent via SMS.
16. Panel integrated with either dual-band, triple-band, quad-band GSM/GPRS industrial graded module, stable and reliable.
Alarm system Specification:
1. Power Voltage: AC110-242V DC9-15V
2. Static Current: <=50mA
3. Alarm Current: <=250mA
4. Batteries: Built-in rechargeable
5. Receive Frequency: 433MHz± 1MHz
6. Alarm volume: >=90dB within 1 meter
7. Dial way: Dual-frequency voice dial
8. Dial parameter: -7± 2dBM(high frequency); -9± 2dBM(low frequency)
9. Max temperature: -15degree~55degree
10. Relative humidity: <80%
11. Dimension of main host: 240× 128× 57mm
GSM Alarm Standard Package list:
Mainframe X1
Remote contol X2
Wireless PIR Motion Sensor X1
Wireless Door magnetic Sensor X1
AC/DC AdaptorX1
User Manual X1
----------------------------------------------------------------------------------------------------------------
