PA66+30%GF red phosphorus flame retardant nylon

Brand:aa

Product detail:

PA66+30%GF red phosphorus flame retardant nylon



Low smoke and low toxicity characteristics



Red phosphorus-based flame retardant nylon

This series of nylon performs excellent electrical insulation properties and dielectric property,in accordance with fire resistance and self-extinguishing of UL94V-0.



Halogen-free red phosphorus flame retardant series of nylon decreased the pollution of wasted electronic plastic products to the environment,in accordance with environmental requirement.Our nylon is a kind of easy molding material,which is applied in electrical and electronic area and solar photovoltaic industry.



Data Sheet for PA66+30%GFred phosphorus flame retardant nylon



Properties	Test Conditions	Test standard	Unit	B2FL6
Mechanical properties
Tensile Strength	5mm/min	ISO527-1/2	Mpa	130
Elongation at break	5mm/min 50mm/min	ISO527-1/2	%	2
Flexural Modulus	2mm/min	ISO178	Mpa	6000
Flexural Strength	2mm/min	ISO178	Mpa	190
Charpy Impact Strength	23°c	ISO179/1eA	KJ/M2	10
Charpy Unnotched Impact Strength	23°c	ISO179/1eA	KJ/M2	45
Thermal Properties
Melting Temperature	DSC.10K/min	ISO3146	°c	225
HDT A	1.8Mpa	ISO75	°c	200
HDT B	0.45Mpa	ISO75	°c	220
Electrical Properties
Surface Resistivity		IEC60093	Ohm	1/.01
Volume Resistivity	Testsotution A	IEC60093	ohm*cm	10/0.1
Physical Properties
Density	23°c	ISO1183	g/cm3	1.49
Damp Absorption	23°c 50%.r.h	ISO62	%	0.9
Water Absorption	23°c saturtion	ISO62	%
Radial Shrinkage	flow	ISO294-4	%
Transverse Shrinkage	transverse	ISO294-4	%
Flame retardant
Flammability Test	1.6/3.0mm	UL94		V-0
Material Description				PA6+30% Red phosphorus flame retardant



Photo:

Appliation:

electric switch



Production equipment:
