Intelligent curtain beam infrared detector for home

Model: KRK-40X-E X:beams quantity

Alarm Output Time:>2ms

Outdoor detecting distance:40m

Indoor detecting distance:15m

Beams:2~10 beams

Contact Rating:30VAC/DC30V0.5Amax

Working Voltage:DC/12~18V

Tamper contact capacity:AC/DC30V0.5Amax

Working Current:Caster≥25mA,Receiver≥42mA

Temperature:-25°C~+55°C

Total  Length:428mm~1688mm

Ralative Humidity:≤95%RH,No condensation

Carrier Wave Frequency:38KHz Infrared ajust carrier wave

Trigger time:<30ms

Frequency:144Hz,129Hz,117Hz,107Hz

Alarm Output:Wire(NO or NC),Or wireless

Response Speed Frequency:≤35ms, ≤39ms, ≤43ms, ≤47ms

Optical axis adjustment angle:180°,(±90°)

Alarm Condition:2 beams adjacent are kept out

Waterproof Grade: E

Case Material:AL and imported light filter

Other accessory Function:OK indicator light,Out sync or sync,Wireless interrupt Alert
