weighing scales 200kg scale weighing SF-918

Click for original picture
Fob Price: 25.00 USD/
MOQ: 200
Payment Terms: delivery withindays since payment
Location: China
  Mr. ping chen    Contact Now 询价
Not exactly what you want? Post a quick Buying Request !


Product Detail

Brand:aa

Product detail:

Digital Crane Scale

Main Features:



1.Zero, Tare and Hold
2.Auto power-off
3.Battery supervision
4.Overload alarm
5.Unit switch
6.Unit switch and Resolution switch
7. Kg/lb/g/oz conversion

8.Aluminium shackle
9.AAA*3 battery







SPECIFICATIONS
Accuracy ClassChinese GB/T 11883-2002 Class
Equivalent to OIML R76
Tare Range100% F.S.
Auto Zero±50% F.S.
Manual Zero±2% F.S.
Zero-tracking0.5e/s
Reading Stable10 seconds
Time
Auto-sleepStable and no action in 3 sec.
Auto-offStable and no action in 3 min.
Overload100% F.S. +9e
Max. Safety Load120% F.S.
Ultimate Load300% F.S.
Battery Life>150hours
Battery2X AAA (rechargeable) battery
Temp.(Op.)10°C~+40°C
Humidity (Op.)91% at 20°C
Display0.7 inch (17.78mm) numerical
Net Weight620g





Trouble-shooting




Symptom

Possible Causes

Solution




discharged battery

replace battery



black display when

defective battery



ON/OFF is pressed

defective ON/OFF

press ON/OFF key




key

for long



no action taken



after TARE or

defective TARE or

clean TARE or



HOLD is pressed

HOLD key

HOLD key



unstable reading

scale in motion

stabilize the load



and scale



scale is damped

dry the scale



dust on PCB board

clean PCB board




unstable system

longer warm-up




power

time



reading is not zero

load-cell stressed



without load

too much or too

hang the scale in




power

storage




scale is not zeroed

keep the scale




before loading

unload and reboot



large error in

re-calibration

re-calibrate the



weight reading

needed

scale




improper unit

switch to preper




unit







Capacity and division





Max.Cap.

Division

Min. cap.

30kg

60lb

0.01kg

0.02lb

0.2kg

0.4lb

50kg

100lb

0.02kg

0.04lb

0.4kg

0.8lb

100kg

200lb

0.05kg

0.1lb

1kg

2lb

150kg

300lb

0.05kg

0.1lb

1kg

2lb

200kg

400lb

0.1kg

0.2lb

2kg

4lb

300kg

600lb

0.1kg

0.2lb

2kg

4lb





ADVICE FOR USE AND CARE



  • Do not overload the scale .This will damage the loadcell and void the warranty.
  • Do not leave load hung on the scale for long.This will decrease the scale's accuracy and shorten the loadcell's life.
  • Inspect shackle and hook before using.
  • When the scale runs out of power,replace the battery with full ones.
  • Do not use the scale under thunder or rain.
  • Do not attempt to repair the scale yourself.Contact your local representative.
