Brand:aa
Product detail:
Hi Dear welcome to our on line factory to choose us get a
happy and reliable purchasinge experience
Lively Team
About Us
Why to choose us?
First ,We are a professional oil drilling pipe manufacture and in this line for more than 15years.That means we are in a high degree of technological maturity.
Second as a leader in the steel screen industrial we have a high sensitivity of the new techniques.So we are trying and trying to study and invent the high quality steel pipe with a lower cost but for a best using effects.Which can help our customers to get more profite without to pay a heavy price
Third,With a comprehensive after- sale system , a comprehensive solution to our customers to worry about .Also it is a important reason why so many customer to choose us
Johnson screens are used for oil and water exploiting.They consist of Vshape profile wire and the longitudinal support rods. Each intersecting pointThe Vshape section plane can avoid blockage ,and make sure of the unimpeded water. The consecutive slot have more open area ,and it can reduce the speed of the water entering to of these wires is fusion welded ,so it has sturdy constriction and good mechanical property. Avoid the sand entering the screen under the great pressure ,so it can filter sand better.
Meanwhile ,the slot can change according to the real condition of the earth.
Advantage:
1. OD(outside diameter):usually 6-5/8" 7" 8-5/8" 9-5/8" 10-3/4" 12" 12-3/4" by our customers' requirements.
2. Material:carbon steel or stainless steel(201,304,304L,316, 316L)
3. Slot size:given by customers. We can do 0.05-2mm.
4. Open area:a maximum open area of 60% is offered facilitating high flow capacity and low inlet resistance resulting in extended well life.
5. Wire and rod dimensions:obtained through well depth, or collapse strength and tensile strength, which are furnished by customers.
6. Connection types:usually STC threads or a passage of welded ring ( plainend or beveled end), both of them are welded together with the portion of screen
Specification of johnson screen
SIZE (inch) | O.D (mm) | SLOT (inch) | LENGTH (m) | Collapse Strength (psi) | Tensile Weight (ton) | Wire size (mm) | RODS (mm) |
4 | 117 | 0.040 | 3 | 395 | 6 | 2.2*3.0 | 3.8mm/22 |
4 | 114.3 | 0.040 | 3 | 395 | 6 | 2.3*3.0 | 3.8mm/22 |
6 | 168.3 | 0.040 | 3 | 252 | 8 | 2.3*3.5 | 3.8mm/32 |
8 | 219.1 | 0.010 | 3 | 399 | 10.5 | 3.0*5.0 | 3.8mm/48 |
8 | 219.1 | 0.020 | 3 | 370 | 10.5 | 3.0*5.0 | 3.8mm/48 |
8 | 219.1 | 0.040 | 3 | 323 | 10.5 | 3.0*5.0 | 3.8mm/48 |
10 | 273.1 | 0.010 | 3 | 206 | 11 | 3.0*5.0 | 3.8mm/50 |
10 | 273.1 | 0.020 | 3 | 191 | 11 | 3.0*5.0 | 3.8mm/50 |
10 | 273.1 | 0.040 | 3 | 167 | 11 | 3.0*5.0 | 3.8mm/50 |
Application
Packing
| MOQ | 60M |
| Payment | T/T OR L/C |
| Port | xingang/shanghai/qingdao |
| Delivery time | 14-30 days depend on the quantity |
Kindly Remain
Proper well screen selection is a critical part of a successful completion. A number of factors influence screen selection, and our technical experts can help you optimize well performance with activities like sieve analysis of representative formation material samples and proper material selection for special downhole corrosive environments.
Thank you so much for your scan of wire wrapped water filter if you have any questions about the products pls don't hesitate to let me know.I'm here always ready to serve you.
Scan our QR Code to get more info.about other model numbers you may also interest
